SQUARE D

Industrial control transformer, Type TF, 1 phase, 100VA, 208V primary, 120V secondary, 50/60Hz

CONTROL XFMR 100VA 208P/120S

SQD9070TF100D3 9070TF100D3 785901905769
386.61 / EA
http://schema.org/OutOfStock
  • Country of Origin: Mexico
  • Depth: 3.34 in
  • Height: 4.18 in
  • Temperature Rise: 55 °C
  • Warranty Length: 18 mth
  • Width: 3.38 in
We offer both product lines with factory installed overcurrent protection fuse blocks. Type TF and EOF transformers consist of two primary fuse blocks and one secondary fuse block, a configuration that meets the majority of overcurrent needs by panel bui
QTY
  • Product Description
  • Features
  • Specifications
We offer both product lines with factory installed overcurrent protection fuse blocks. Type TF and EOF transformers consist of two primary fuse blocks and one secondary fuse block, a configuration that meets the majority of overcurrent needs by panel bui
  • Primary Voltage
    • 208 V 120 V
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Phenyl glycidyl ether, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Material
    • copper: winding
  • Accessories
    • 9070FP1
    • 9070FSC1
    • 9070FB3A
    • 9070FB2A
    • 9070SF41A
  • Rated Power In Va
    • 100 VA UL
    • 100 VA CSA
    • 100 VA NOM
    • 100 VA CE
  • Fuse Type
    • 0.41 x 1.50 in CC top
  • Product Certifications
    • CSA file LR37055 guide 184-N-90
    • UL listed file E61239
  • Important Information Attributes
    • Country Id : US
    • B2B Bullet Point 1 : Type TF units are designed to free up space by fuse blocks pre-wired and factory installed saving you time
    • B2B Bullet Point 2 : Provides reliable power using voltage regulation
    • B2B Bullet Point 3 : Protects against accidental shocks through the use of touch-safe terminals
    • B2B Bullet Point 4 : Conforms to the electrical characteristics in the data sheet by the Underwriters Laboratories (UL)
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-08-13
    • ETIM 10 : EC002486
    • Html Descr : The Type T MultiTap Universal Control Transformer allows 120V — or near 120V — control power from a wide variety of available source voltages. Broad voltage coverage allows the MultiTap Universal Control Transformer to meet a wide variety of applicati
    • Manufacturer : Schneider Electric
    • Device Type : Transformer - dry
    • Serviceability : No
    • Traceability : No
    • Legacy WEEE Scope : In
    • WEEE Product Category : 4
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS Eur In Scope : Yes
    • ROHS Eur Status : Compliant with Exemptions
    • ROHS Eur Conformity Date : 1905
    • ROHS Eur Full Compliance Status : Compliant with Exemptions
    • ROHS Eur Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Electrical Connection : screw clamp terminals
    • Insulation Temperature : 105 °C
    • Package Weight Lbs : 2.046 kg
    • Phase : 1 phase
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : Industrial Control Transformer
    • Range Of Product : TF
    • Returnability : Yes
    • Sustainable Packaging : No
    • Temperature Rise : 55 °C
    • Relationshiptype : Compatible relationship
  • General Attributes
    • Phase : 1 phase
    • Product Or Component Type : Industrial Control Transformer
    • Range Of Product : TF
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=454243&lang=en-us
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1308008EN
    • Eu Rohs Directive : Compliant with Exemptions
    • Nema Degree Of Protection : not rated (open device)
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : No
    • Product Compatibility : FSC1
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : Mexico
    • Height : 4.18 in
    • Width : 3.38 in
    • Depth : 3.34 in
