SQUARE D

TeSys GV2, interconnection block, to connect GV2 and LC1D09 to D38 contactor

MANUAL STARTER COMBO BLOCK 600

SQDGV2AF3 GV2AF3 3389110569063
3.93 / EA
http://schema.org/OutOfStock
TeSys GV2, interconnection block, to connect GV2 and LC1D09 to D38 contactor
  • Country of Origin: France
  • Net Weight: 0.016 kg
  • Warranty Length: 18 mth
  • Weight: 0.016 kg
TeSys GV accessory, combination block for motor starter assembly. For the connection between a motor circuit breaker GV2 or a fuse carrier LS1D32 and contactor LC1D09-D38. To be used when the assembly is mounted directly on DIN rails. Sold in lots of 10 units.
QTY
  • Product Description
  • Specifications
TeSys GV accessory, combination block for motor starter assembly. For the connection between a motor circuit breaker GV2 or a fuse carrier LS1D32 and contactor LC1D09-D38. To be used when the assembly is mounted directly on DIN rails. Sold in lots of 10 units.
  • Environmental data
    • Packaging Made With Recycled Cardboard : Yes
    • Environmental Disclosure : ENVPEP2207006
    • Packaging Without Single Use Plastic : Yes
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Circularity Profile : ENVEOLI2207006
    • Take-Back : No
  • Complementary
    • Net Weight : 0.016 kg
    • [Ie] Rated Operational Current : 32 A
    • Poles Description : 3P
    • Product Compatibility : LC1D09...D38
  • Specifications
    • Country of Origin : France
    • Weight : 0.016 kg
    • Accessory / Separate Part Category : connection accessory
    • Product Or Component Type : combination block
    • Product Name : FT
    • Range : Linergy
    • Range Compatibility : TeSys GV2 || TeSys Deca
    • Device Short Name : GV2AF
  • Contractual warranty
    • Warranty : 18 months
