TeSys Deca contactor, 3 poles (3NO), for motor control applications up to 18A/690V AC-3/3e (7.5kW@400V). They can be used to create motor starters for almost any type of application. It provides a 208V 50/60Hz AC coil, 1NO+1NC built-in auxiliary contacts (NC mirror certified), connection by ring-lugs screw terminals. For operating rates until 3600 cycles/hour and environments until 60°C, it procures high reliability and durability. Compact (45mm width), DIN-rail mounting or screw fixing. Power contacts have a 25A resistive load rating. Multi standards certified (IEC, UL, CSA, CCC, EAC, Marine). Contactor has one normally open and one normally closed auxiliary contact built-in as standard. The NC contact is mirror certified. Ring-lug screw terminals are used for load and auxiliary connections. An extensive line of accessories makes it easy to meet the requirements of most applications. The contactor is 3.35 inches tall, 1.77 inches wide and 3.62 inches deep. It weighs 0.80 lbs. Contactor is certified to UL, CSA, IEC, CCC, EAC and Marine standards.

• Prop 65
• WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov

• Environment
• Product Certifications : UL || CCC || CSA || Marine || UKCA || EAC || CB Scheme
• Height : 85 mm
• Standards : CSA C22.2 No 14 || EN 60947-4-1 || EN 60947-5-1 || IEC 60947-4-1 || IEC 60947-5-1 || UL 60947-4-1 || IEC 60335-1:Clause 30.2 || IEC 60335-2-40:Annex JJ || UL 60335-2-40:Annex JJ || CSA C22.2 No 60947-4-1
• Climatic Withstand : IACS E10 exposure to damp heat || IEC 60947-1 Annex Q category D exposure to damp heat
• Net Weight : 0.365 kg
• Flame Retardance : V1 conforming to UL 94
• Protective Treatment : THIEC 60068-2-30
• Ip Degree Of Protection : IP20 front face IEC 60529
• Mechanical Robustness : vibrations contactor open 2 Gn, 5...300 Hz) || vibrations contactor closed 4 Gn, 5...300 Hz) || shocks contactor open 10 Gn for 11 ms) || shocks contactor closed 15 Gn for 11 ms)
• Operating Altitude : 0...9842.52 ft (0...3000 m)
• Fire Resistance : 850 °C IEC 60695-2-1
• Width : 45 mm
• Depth : 92 mm
• Permissible Ambient Air Temperature Around The Device : -40-60 °C || 60-70 °C with derating
• Contractual warranty
• Warranty : 18 months
• Environmental data
• Rohs Exemption Information : Yes
• Packaging Made With Recycled Cardboard : Yes
• Mercury Free : Yes
• Environmental Disclosure : ENVPEP1501004
• Packaging Without Single Use Plastic : Yes
• Toxic Heavy Metal Free : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• California Proposition 65 : WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
• Reach Free Of Svhc : Yes
• Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Circularity Profile : ENVEOLI1501004
• Take-Back : No
• Pvc Free : Yes
• Sustainable Packaging : Yes
• Eu Rohs Directive : Compliant
• Carbon Footprint (Kg Co2 Eq, Total Life Cycle) : 26.9
• Complementary
• Non-Overlap Time : 1.5 ms on de-energisation between NC and NO contact || 1.5 ms on energisation between NC and NO contact
• Minimum Switching Current : 5 mA for signalling circuit
• Power Dissipation Per Pole : 1.56 W AC-1
• Average Impedance : 2.5 mOhm - Ith 25 A 50 Hz for power circuit
• Auxiliary Contact Composition : 1 NO + 1 NC
• [Ith] Conventional Free Air Thermal Current : 25 A (at 60 °C) for power circuit || 10 A (at 60 °C) for signalling circuit
• Control Circuit Voltage Limits : 0.3...0.6 Uc (-40-60 °C):drop-out AC 50/60 Hz || 0.8...1.1 Uc (-40-60 °C):operational AC 50 Hz || 0.85...1.1 Uc (-40-60 °C):operational AC 60 Hz
• Mounting Support : plate || rail
• Control Circuit Type : AC 50/60 Hz
• Safety Reliability Level : B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1 || B10d = 20000000 cycles contactor with mechanical load EN/ISO 13849-1
• Pollution Degree : 3
• Insulation Resistance : > 10 MOhm for signalling circuit
• Rated Breaking Capacity : 250 A at 440 V for power circuit conforming to IEC 60947
• Irms Rated Making Capacity : 250 A at 440 V for power circuit conforming to IEC 60947 || 140 A AC for signalling circuit conforming to IEC 60947-5-1 || 250 A DC for signalling circuit conforming to IEC 60947-5-1
• Associated Fuse Rating : 10 A gG for signalling circuit conforming to IEC 60947-5-1 || 40 A gG at <= 690 V coordination type 1 for power circuit || 25 A gG at <= 690 V coordination type 2 for power circuit
• Inrush Power In Va : 70-70 VA 60 Hz cos phi 0.75 (at 20 °C) || 70-70 VA 50 Hz cos phi 0.75 (at 20 °C)
• [Uimp] Rated Impulse Withstand Voltage : 6 kV IEC 60947
• Pole Contact Composition : 2 NO + 2 NC
• Connections - Terminals : control circuit: lugs-ring terminals - external diameter: 8 mm || power circuit: lugs-ring terminals - external diameter: 8 mm
• Coil Technology : without built-in suppressor module
• Operating Time : 12...22 ms closing || 4...19 ms opening
• Minimum Switching Voltage : 17 V for signalling circuit
• Maximum Operating Rate : 3600 cyc/h at 60 °C
• Signalling Circuit Frequency : 25...400 Hz
• Tightening Torque : control circuit 1.7 N.m lugs-ring terminals flat Ø 6 mm M3.5 || control circuit 1.7 N.m lugs-ring terminals Philips No 2 M3.5 || power circuit 1.7 N.m lugs-ring terminals flat Ø 8 mm M3.5 || power circuit 1.7 N.m lugs-ring terminals Philips No 2 M3.5 || control circuit 1.7 N.m lugs-ring terminals pozidriv No 2 M3.5 || power circuit 1.7 N.m lugs-ring terminals pozidriv No 2 M3.5
• Electrical Durability : 0.8 Mcycles 25 A AC-1 <= 440 V
• Mechanical Durability : 15 Mcycles
• Auxiliary Contacts Type : mechanically linked 1 NO + 1 NC IEC 60947-5-1 || mirror contact 1 NC IEC 60947-4-1
• Compatibility Code : LC1D
• Hold-In Power Consumption In Va : 7.5-7.5 VA 60 Hz cos phi 0.3 (at 20 °C) || 7-7 VA 50 Hz cos phi 0.3 (at 20 °C)
• Overvoltage Category : III
• [Ui] Rated Insulation Voltage : power circuit 690 V IEC 60947-4-1 || power circuit 600 V CSA || power circuit 600 V UL || signalling circuit 690 V IEC 60947-1 || signalling circuit 600 V CSA || signalling circuit 600 V UL
• [Icw] Rated Short-Time Withstand Current : 105 A 40 °C - 10 s for power circuit || 210 A 40 °C - 1 s for power circuit || 30 A 40 °C - 10 min for power circuit || 61 A 40 °C - 1 min for power circuit || 100 A - 1 s for signalling circuit || 120 A - 500 ms for signalling circuit || 140 A - 100 ms for signalling circuit
• Heat Dissipation : 2-3 W at 50/60 Hz
• Protective Cover : with
• Specifications
• Country of Origin : France
• Width : 45 mm
• Height : 85 mm
• Weight : 0.365 kg
• [Uc] Control Circuit Voltage : 208 V AC 50/60 Hz
• [Ue] Rated Operational Voltage : power circuit <= 690 V AC 25...400 Hz
• Range Of Product : TeSys Deca
• Contactor Application : resistive load
• Product Or Component Type : contactor
• Utilisation Category : AC-1
• [Ie] Rated Operational Current : 25 A (at <60 °C) at <= 440 V AC AC-1 for power circuit
• Poles Description : 4P
• Device Short Name : LC1D
