SQUARE D

Mini circuit breaker, QO, 20A, 1 pole, 240/415VAC, 3kA, plug in

MINIATURE CIRCUIT BREAKER 240V

SQDQOXD120 QOXD120 785901395669
30.88 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QO, 20A, 1 pole, 240/415VAC, 3kA, plug in-1
  • Country of Origin: USA
  • Depth: 74 mm
  • Height: 76 mm
  • Net Weight: 0.277 kg
  • Warranty Length: 18 mth
  • Weight: 0.277 kg
  • Width: 19 mm
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 240/415VAC. This unit provides 3kA breaking capacity and plug in mounting. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
QTY
  • Product Description
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 240/415VAC. This unit provides 3kA breaking capacity and plug in mounting. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Environment
    • Ambient Air Temperature For Operation : 40 °C
  • Contractual warranty
    • Warranty : 18 months
  • Environmental data
    • Packaging Made With Recycled Cardboard : No
    • Environmental Disclosure : ENVPEP2111016
    • Halogen Content Performance : Halogen free product
    • Packaging Without Single Use Plastic : Yes
    • Scip Number : af42fb01-813d-40c0-ae28-b8b3299dbc99
    • Circularity Profile : N/A
    • Take-Back : No
  • Complementary
    • Height : 76 mm
    • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
    • Number Of Spaces Required : 1
    • Net Weight : 0.277 kg
    • Breaking Capacity : Icu 3 kA 240/415 V AC
    • Width : 19 mm
    • Depth : 74 mm
  • Specifications
    • Country of Origin : United States
    • Width : 19 mm
    • Height : 76 mm
    • Weight : 0.277 kg
    • Circuit Breaker Type : standard
    • Range Of Product : QO
    • Product Or Component Type : miniature circuit-breaker
    • Mounting Mode : plug-in
    • Poles Description : 1P
    • Line Rated Current : 20 A
    • [Ue] Rated Operational Voltage : 240/415 V AC
