Schneider Electric at Mayer

Plug in relay, Type KF, flange mounted, 1 HP at 277 VAC, 10A resistive at 277 VAC, DPDT, 2 NO, 2 NC, 120 VAC coil

Plug in relay, Type KF, flange

SQD8501KFR12V20 8501KFR12V20 785901342519
35.18 / EA
http://schema.org/OutOfStock
Mayer-DDS-Plug in relay, Type KF, flange mounted, 1 HP at 277 VAC, 10A resistive at 277 VAC, DPDT, 2 NO, 2 NC, 120 VAC coil-2
  • Country of Origin: China
  • Depth: 1.4 in
  • Height: 2.75 in
  • Width: 1.4 in
8501KF universal relays are designed for multipole switching applications at 300 VAC or lower. These relays are designed to be flange mounted into a panel. This flange mounted relay has DPDT contact arrangements. It has two normally open and two normally
QTY
  • Product Description
  • Features
  • Specifications
8501KF universal relays are designed for multipole switching applications at 300 VAC or lower. These relays are designed to be flange mounted into a panel. This flange mounted relay has DPDT contact arrangements. It has two normally open and two normally
  • Uc Control Circuit Voltage
    • 120 V AC
  • Rated Power In Hp
    • 1 hp 277 V AC
    • 0.33 hp 120 V AC
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproduc
  • Carbon Footprint Of The Installation Phase A5
    • 0.0006949047
    • 0 kg CO2 eq.
  • Carbon Footprint Of The End Of Life Phase C1 To C4
    • 0.1 kg CO2 eq.
    • 0.1354907889
  • Operating Time
    • 20 ms - pick-up
    • 20 ms - drop-out
  • Maximum Switching Voltage
    • 300 V AC
    • 30 V DC
  • Carbon Footprint Of The Manufacturing Phase A1 To A3
    • 0.6 kg CO2 eq.
    • 0.573652338
  • Market Segmentation
    • Commercial
    • Industrial
  • Persona Type Names
    • Charge Point Operator
    • End User
    • Contractor
    • Original Equipment Manufacturer
    • OEM - Control Panelbuilder
    • Panel Builder
    • Electrician
    • System Integrator
    • IT Channel Partner
  • Carbon Footprint Of The Use Phase B2 B3 B4 B6
    • 25 kg CO2 eq.
    • 24.5363507625
  • Persona Type Ids
    • BM9
    • EU
    • LC
    • OM
    • OM8
    • PB
    • SC
    • SI
    • VR
  • Carbon Footprint Of The Distribution Phase A4
    • 0.011269773
    • 0 kg CO2 eq.
  • Market Segmentation Id
    • COMMERCIAL
    • INDUSTRIAL
  • Rated Breaking Capacity
    • 3 A 120 V AC inductive control circuit UL 508
    • 3 A 120 V AC inductive c
  • Product Certifications
    • UL Recognized
    • CSA
    • CE
  • Important Information Attributes
    • Country Id : US
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-07-23
    • Manufacturing Carbon Footprint : 0.573652338
    • Distribution Carbon Footprint : 0.011269773
    • Installation Carbon Footprint : 0.0006949047
    • Use Carbon Footprint : 24.5363507625
    • End Of Life Carbon Footprint : 0.1354907889
    • Legacy WEEE Scope : Out
    • WEEE Product Category : 5
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
    • Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
    • ROHS Eur In Scope : No
    • ROHS Eur Status : Compliant
    • ROHS Eur Conformity Date : 1930
    • ROHS Eur Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS Eur Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : Yes
    • China ROHS Label : 1
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 1 - GSC certified
    • Tier Id : 2
    • Tier : 2
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Contacts Material : silver alloy (AgNi)
    • Control Type : without test button
    • Local Signalling : no indicator
    • Mounting Support : flange
    • Package Weight Lbs : 86.182 g
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : relay
    • Range Of Product : 8501K
    • Relay Type : general purpose
    • Returnability : Yes
    • Shape Of Pin : spade
    • Sustainable Packaging : No
    • Switch Function : DPDT
    • Total Lifecycle Carbon Footprint : 25 kg CO2 eq.
    • Carbon Footprint Kg Co2 Eq Total Life Cycle : 25.2574585671
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=421969144&lang=en-us
    • Take Back : No
    • Reach Free Shvc : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : X
    • Carbon Footprint : 25.2574585671
    • Ambient Air Temperature For Operation : -40-131 °F
    • Environmental Disclosure : ENVPEP1406038EN
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Free Of Svhc : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
  • Specifications
    • Country of Origin : China
    • Height : 2.75 in
    • Width : 1.4 in
    • Depth : 1.4 in
  • General Attributes
    • Product Or Component Type : relay
    • Range Of Product : 8501K
