This product is part of the Modicon M580 range, an offer of Programmable Automation Controllers (PAC) and safety Programmable Logic Controllers (PLC) with built-in Ethernet. This processor module offers a maximum of 8 rack configuration and 144 applicati

• Communication Module Processor Capacity
• 16 AS-Interface module
• 4 Ethernet communication module
• Current Consumption
• 295 mA 24 V DC
• Prop 65
• WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
• Carbon Footprint Of The Installation Phase A5
• 0.0031837504
• 0 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4
• 0.4 kg CO2 eq.
• 0.36789527
• Application Specific I O
• counter
• SSI encoder
• motion control
• accurate time stamping
• HART
• serial link
• Standards
• IEC 61131-2
• IEC 61010-2-201
• UL 61010-2-201
• CSA C22.2 No 61010-2-201
• IACS E10
• EN/IEC 61000-6-5, interface type 1 and type 2
• EN/IEC 61850-3, location G
• Status Led
• 1 LED (Green) processor running (RUN)
• 1 LED (Red) processor or system fault (ERR)
• 1 LED (R
• Carbon Footprint Of The Manufacturing Phase A1 To A3
• 64 kg CO2 eq.
• 63.8222183099
• Environmental Characteristic
• hazardous location class I division 2
• Carbon Footprint Of The Use Phase B2 B3 B4 B6
• 181 kg CO2 eq.
• 180.84
• Relative Humidity
• 5-95 % 55-55 °C without condensation
• Directives
• 2014/35/EU - low voltage directive
• 2014/30/EU - electromagnetic compatibility
• Carbon Footprint Of The Distribution Phase A4
• 0.1123814906
• 0.1 kg CO2 eq.
• Number Of Remote I O Station
• 16 - 2 remote drop
• Operating Altitude
• 0...6561.68 ft (0...2000 m)
• 2000...5000 m with derating factor
• Number Of Instructions Per Ms
• 30 Kinst/ms 65 % Boolean + 35 % fixed arithmetic
• 40 Kinst/ms 100 % Boolean
• Integrated Connection Type
• 1 Ethernet TCP/IP service port
• 2 Ethernet TCP/IP device network
• USB type mini B
• Product Certifications
• CE
• UL
• CSA
• RCM
• EAC
• Merchant Navy
• Memory Description
• expandable flash, 4 GB data storage
• integrated RAM, 10 kB system memory
• in

• Assets
• CAD : https://download.schneider-electric.com/files?p_Doc_Ref=MCADID0000202_3D-CAD
• Important Information Attributes
• B2B Bullet Point 1 : This product is TAA,BAA via COTS compliant.
• Local Data Status : Publishable
• Local Publishable Date : 5/31/2025
• HTML Description : Processor module M580 - Level 4 - RemoteRange of product : Modicon M580Product or component type : Processor module
• Manufacturer : Schneider Electric
• Device Type : PLC System - PLC CPU
• Serviceability : Yes
• Traceability : Yes
• Field Service Division : IDIBS
• Average Life Duration : 20 year(s)
• Manufacturing Carbon Footprint : 63.82221831
• Distribution Carbon Footprint : 0.112381491
• Installation Carbon Footprint : 0.00318375
• Use Carbon Footprint : 180.84
• End Of Life Carbon Footprint : 0.36789527
• Legacy WEEE Scope : Out
• WEEE Product Category : 5
• Scope Perimeter : At least in Europe
• EOLI Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1312016EN
• Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : CONTAINS_SVHC
• Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
• ROHS EUR In Scope : No
• ROHS EUR Status : Compliant with Exemptions
• ROHS EUR Conformity Date : 1949
• ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
• ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
• China ROHS In Scope : Yes
• China ROHS Label : 5
• With Recycled Cardboard : Yes
• Without Single Use Plastic : No
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• WD Status : 1 - GSC certified
• Control Channels : programmable loops
• Number Of Application Specific Channel : 144
• Number Of Distributed Equipment : 64
• Package Weight Lbs : 875.000 g
• Product Availability : Stock - Normally stocked in distribution facility
• Product Or Component Type : processor module
• Range Of Product : Modicon M580
• Returnability : Yes
• Shock Resistance : 30 gn
• Sustainable Packaging : No
• Total Lifecycle Carbon Footprint : 245 kg CO2 eq.
• Vibration Resistance : 3 gn
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 245.1456788
• Relationship Type : Compatible relationship
• Pep Code : ENVPEP1312016EN
• Pep Verification Date : 12/1/2022
• PCR Version : PCR-ed3-EN-2015 04 02
• Type Of Verification For The Pep : Independent external review
• Product Weight In G : 871
• Functional Unit Description : The Modicon M580 ePAC module provides cutting-edge features and high-end performances for small to large process automation for 10 years with a 100% use rate. Typical electrical power is 7,08 W (295 mA at 24 V DC)
• Functional Unit Quantity : 1
• Functional Unit Unit : unit
• Reference Lifetime In Y : 10
• Energy Consumption On Product Lifetime In Kwh : 558.1872
• Energy Model Manufacturing A1 A3 : Energy model used: France
• Energy Model Installation A5 : Electricity grid mix; AC; consumption mix, at consumer; 230V; FR / Electricity mix; AC; consumption mix, at consumer; 120V; US / Electricity grid mix; AC; consumption mix, at consumer; 230V; CH
• Energy Model Use B6 : Electricity grid mix; AC; consumption mix, at consumer; 230V; FR / Electricity mix; AC; consumption mix, at consumer; 120V; US / Electricity grid mix; AC; consumption mix, at consumer; 230V; CH
• Energy Model End Of Life C1 C4 : Electricity grid mix; AC; consumption mix, at consumer; 230V; FR / Electricity mix; AC; consumption mix, at consumer; 120V; US / Electricity grid mix; AC; consumption mix, at consumer; 230V; CH
• Components For Re Use Kg Total Life Cycle : 0.000899624
• Components For Re Use Kg Manufacturing A1 A3 : 0
• Components For Re Use Kg Distribution A4 : 0
• Components For Re Use Kg Installation A5 : 0
• Components For Re Use Kg Operational Energy Use B6 : 0
• Components For Re Use Kg End Of Life C1 C4 : 0.000899624
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Total Life Cycle : 0.010882943
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Manufacturing A1 A3 : 0.01084763
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Distribution A4 : 4.5E-09
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Installation A5 : 1E-10
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb Operational Energy Use B6 : 0.000035305
• Depletion Of Abiotic Resources Elements Kg Equivalent Sb End Of Life C1 C4 : 2.7E-09
• Depletion Of Abiotic Resources Fossil Fuels Mj Total Life Cycle : 2765.824592
• Depletion Of Abiotic Resources Fossil Fuels Mj Manufacturing A1 A3 : 648.4451878
• Depletion Of Abiotic Resources Fossil Fuels Mj Distribution A4 : 1.578840845
• Depletion Of Abiotic Resources Fossil Fuels Mj Installation A5 : 0.041274359
• Depletion Of Abiotic Resources Fossil Fuels Mj Operational Energy Use B6 : 2114.6
• Depletion Of Abiotic Resources Fossil Fuels Mj End Of Life C1 C4 : 1.159288732
• Exported Energy Mj By Energy Vector Total Life Cycle : 0.000183475
• Exported Energy Mj By Energy Vector Manufacturing A1 A3 : 0.00001499
• Exported Energy Mj By Energy Vector Distribution A4 : 0
• Exported Energy Mj By Energy Vector Installation A5 : 0.000168485
• Exported Energy Mj By Energy Vector Operational Energy Use B6 : 0
• Exported Energy Mj By Energy Vector End Of Life C1 C4 : 0
• Hazardous Waste Disposed Of Kg Total Life Cycle : 204.559277
• Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 199.8188498
• Hazardous Waste Disposed Of Kg Distribution A4 : 0
• Hazardous Waste Disposed Of Kg Installation A5 : 1.563E-07
• Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 3.5152
• Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 1.225227113
• Materials For Energy Recovery Kg Total Life Cycle : 0.091031768
• Materials For Energy Recovery Kg Manufacturing A1 A3 : 0
• Materials For Energy Recovery Kg Distribution A4 : 0
• Materials For Energy Recovery Kg Installation A5 : 0
• Materials For Energy Recovery Kg Operational Energy Use B6 : 0
• Materials For Energy Recovery Kg End Of Life C1 C4 : 0.091031768
• Materials For Recycling Kg Total Life Cycle : 0.645772894
• Materials For Recycling Kg Manufacturing A1 A3 : 0.061362563
• Materials For Recycling Kg Distribution A4 : 0
• Materials For Recycling Kg Installation A5 : 0.058528747
• Materials For Recycling Kg Operational Energy Use B6 : 0
• Materials For Recycling Kg End Of Life C1 C4 : 0.525881585
• Net Use Of Fresh Water M3 Total Life Cycle : 2165.85759
• Net Use Of Fresh Water M3 Manufacturing A1 A3 : 0.657369871
• Net Use Of Fresh Water M3 Distribution A4 : 1.00573E-05
• Net Use Of Fresh Water M3 Installation A5 : 0.000000348
• Net Use Of Fresh Water M3 Operational Energy Use B6 : 2165.2
• Net Use Of Fresh Water M3 End Of Life C1 C4 : 0.000209745
• Non Hazardous Waste Disposed Of Kg Total Life Cycle : 216.140145
• Non Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 17.13171127
• Non Hazardous Waste Disposed Of Kg Distribution A4 : 0.003992799
• Non Hazardous Waste Disposed Of Kg Installation A5 : 0.000432147
• Non Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 199
• Non Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 0.004008747
• Ozone Depletion Kg Equivalent Cfc 11 Total Life Cycle : 0.000047458
• Ozone Depletion Kg Equivalent Cfc 11 Manufacturing A1 A3 : 8.8208E-06
• Ozone Depletion Kg Equivalent Cfc 11 Distribution A4 : 2E-10
• Ozone Depletion Kg Equivalent Cfc 11 Installation A5 : 0
• Ozone Depletion Kg Equivalent Cfc 11 Operational Energy Use B6 : 0.000038623
• Ozone Depletion Kg Equivalent Cfc 11 End Of Life C1 C4 : 1.39E-08
• Radioactive Waste Disposed Of Kg Total Life Cycle : 0.945803923
• Radioactive Waste Disposed Of Kg Manufacturing A1 A3 : 0.009102461
• Radioactive Waste Disposed Of Kg Distribution A4 : 2.8438E-06
• Radioactive Waste Disposed Of Kg Installation A5 : 0.000000085
• Radioactive Waste Disposed Of Kg Operational Energy Use B6 : 0.93669
• Radioactive Waste Disposed Of Kg End Of Life C1 C4 : 8.5327E-06
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 5175.268797
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 731.5173239
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 1.586814789
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.041513578
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 4440.7
• Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 1.423144484
• Total Use Of Primary Energy During The Life Cycle Mj Total Life Cycle : 5895.984775
• Total Use Of Primary Energy During The Life Cycle Mj Manufacturing A1 A3 : 759.1296596
• Total Use Of Primary Energy During The Life Cycle Mj Distribution A4 : 1.58896162
• Total Use Of Primary Energy During The Life Cycle Mj Installation A5 : 0.041577982
• Total Use Of Primary Energy During The Life Cycle Mj Operational Energy Use B6 : 5133.8
• Total Use Of Primary Energy During The Life Cycle Mj End Of Life C1 C4 : 1.424575704
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 720.6849092
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 27.61131338
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.002117593
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 6.45746E-05
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 693.07
• Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0.001413637
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 6.211497653
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 6.211497653
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 5169.063433
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 725.3119601
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 1.586814789
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.041513578
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 4440.7
• Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 1.423144484
• Use Of Non Renewable Secondary Fuels Mj Total Life Cycle : 0
• Use Of Non Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
• Use Of Non Renewable Secondary Fuels Mj Distribution A4 : 0
• Use Of Non Renewable Secondary Fuels Mj Installation A5 : 0
• Use Of Non Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
• Use Of Non Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
• Use Of Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 720.6849092
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 27.61131338
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.002117593
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 6.45746E-05
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 693.07
• Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0.001413637
• Use Of Renewable Secondary Fuels Mj Total Life Cycle : 0
• Use Of Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
• Use Of Renewable Secondary Fuels Mj Distribution A4 : 0
• Use Of Renewable Secondary Fuels Mj Installation A5 : 0
• Use Of Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
• Use Of Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
• Use Of Secondary Materials Kg Total Life Cycle : 0.170294812
• Use Of Secondary Materials Kg Manufacturing A1 A3 : 0.170294812
• Use Of Secondary Materials Kg Distribution A4 : 0
• Use Of Secondary Materials Kg Installation A5 : 0
• Use Of Secondary Materials Kg Operational Energy Use B6 : 0
• Use Of Secondary Materials Kg End Of Life C1 C4 : 0
• Air Pollution M3 Total Life Cycle : 18501.11002
• Air Pollution M3 Manufacturing A1 A3 : 5869.026995
• Air Pollution M3 Distribution A4 : 4.780481455
• Air Pollution M3 Installation A5 : 0.126969718
• Air Pollution M3 Operational Energy Use B6 : 12617
• Air Pollution M3 End Of Life C1 C4 : 10.17556995
• Water Pollution M3 Total Life Cycle : 14170.74805
• Water Pollution M3 Manufacturing A1 A3 : 5214.039085
• Water Pollution M3 Distribution A4 : 18.48012559
• Water Pollution M3 Installation A5 : 0.482822289
• Water Pollution M3 Operational Energy Use B6 : 8919.5
• Water Pollution M3 End Of Life C1 C4 : 18.24601878
• Acidification Of Soil And Water Kg Equivalent So2 Total Life Cycle : 0.352508638
• Photochemical Ozone Formation Kg Equivalent C2h4 Total Life Cycle : 0.036642722
• Water Eutrophication Kg Equivalent P04 3 Total Life Cycle : 0.07316683
• Acidification Of Soil And Water Kg Equivalent So2 Manufacturing A1 A3 : 0.09151736
• Acidification Of Soil And Water Kg Equivalent So2 Distribution A4 : 0.000513103
• Acidification Of Soil And Water Kg Equivalent So2 Installation A5 : 1.32654E-05
• Acidification Of Soil And Water Kg Equivalent So2 Operational Energy Use B6 : 0.26015
• Acidification Of Soil And Water Kg Equivalent So2 End Of Life C1 C4 : 0.000314909
• Global Warming Kg Equivalent Co2 Total Life Cycle : 245.1456788
• Global Warming Kg Equivalent Co2 Manufacturing A1 A3 : 63.82221831
• Global Warming Kg Equivalent Co2 Distribution A4 : 0.112381491
• Global Warming Kg Equivalent Co2 Installation A5 : 0.00318375
• Global Warming Kg Equivalent Co2 Operational Energy Use B6 : 180.84
• Global Warming Kg Equivalent Co2 End Of Life C1 C4 : 0.36789527
• Photochemical Ozone Formation Kg Equivalent C2h4 Manufacturing A1 A3 : 0.008426516
• Photochemical Ozone Formation Kg Equivalent C2h4 Distribution A4 : 3.66157E-05
• Photochemical Ozone Formation Kg Equivalent C2h4 Installation A5 : 9.915E-07
• Photochemical Ozone Formation Kg Equivalent C2h4 Operational Energy Use B6 : 0.02815
• Photochemical Ozone Formation Kg Equivalent C2h4 End Of Life C1 C4 : 2.85989E-05
• Water Eutrophication Kg Equivalent P04 3 Manufacturing A1 A3 : 0.026865034
• Water Eutrophication Kg Equivalent P04 3 Distribution A4 : 0.000118178
• Water Eutrophication Kg Equivalent P04 3 Installation A5 : 3.2238E-06
• Water Eutrophication Kg Equivalent P04 3 Operational Energy Use B6 : 0.04605
• Water Eutrophication Kg Equivalent P04 3 End Of Life C1 C4 : 0.000130394
• Warranty In Months : 18
• General Attributes
• Product Or Component Type : processor module
• Range Of Product : Modicon M580
• Environment Attributes
• ROHS Exemption Information : Yes
• China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=331582151&lang=en-us
• Take Back : No
• Recycled Metal Content At Cr Level : 0%
• China ROHS Regulation : X
• Mercury Free : Yes
• Carbon Footprint : 245.1456788
• Circularity Profile : ENVEOLI1312016EN
• Environmental Disclosure : ENVPEP1312016EN
• EU ROHS Directive : Pro-active compliance (Product out of EU RoHS legal scope)
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : No
• Reach Regulation : Reference contains Substances of Very High Concern above the threshold
• Pep Code : ENVPEP1312016EN
• Pep Verification Date : 12/1/2022
• PCR Version : PCR-ed3-EN-2015 04 02
• Type Of Verification For The Pep : Independent external review
• Specifications
• Country of Origin : France
• Compliance : TAA | BAA via COTS
