Power distribution module, Modicon TM5, for I/O 24V DC, 1 Safety related output

Safe supply I/O supply, 24 V,

SQDTM5SPS10FS TM5SPS10FS 3606480941092
954.81 / EA
http://schema.org/OutOfStock
Mayer-DDS-Power distribution module, Modicon TM5, for I/O 24V DC, 1 Safety related output-1
  • Certifications: CSA, CULus
  • Current: 25 mA
  • Net Weight: 0.061 kg
  • Standard: CSA C22.2 No 142, CSA C22.2 No 213, IEC 61131-2, UL 508
  • Storage Temperature: -25-70 °C
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safety power distribution module provides a rated supply voltage of 24V DC, 10A. It supplies a 10A current for IO power segment. This safety power distribution module provides a 24V DC, 10A current to associated safety IO modules. It features 2 LEDs for power supply, 2 LEDs for safety status and 20 LEDs for input status signaling. It is furnished with 2 wires for electrical connection. Its housing colour is red. It weighs 0.061kg. It measure 75mm deep, 25mm wide, 99mm high. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon TM5CSLC safety logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
QTY
  • Product Description
  • Specifications
This product is part of the Modicon TM5 range, an High-Performance and Safe IP20 Modular I/O System. This safety power distribution module provides a rated supply voltage of 24V DC, 10A. It supplies a 10A current for IO power segment. This safety power distribution module provides a 24V DC, 10A current to associated safety IO modules. It features 2 LEDs for power supply, 2 LEDs for safety status and 20 LEDs for input status signaling. It is furnished with 2 wires for electrical connection. Its housing colour is red. It weighs 0.061kg. It measure 75mm deep, 25mm wide, 99mm high. The Modicon TM5 meets the typical requirements of production and packaging machinery, as well as material handling and assembly systems. This product is certified by GOST-R, C-Tick, cULus and CSA. It meets IEC 61131-2, UL 508, CSA C22.2 No 213 and CSA C22.2 No 142 standards. It is compatible with Modicon TM5CSLC safety logic controller. It is installed by mounting on a 35mm DIN rail. This modular IO system provides a flexible and scalable configuration of remote or distributed IO islands by connection with Modicon and PacDrive 3 controllers. Flexible and scalable, designed for complex machines.
  • Environment
    • Product Certifications : cULus || CSA
    • Resistance To Electromagnetic Fields : 1 V/m 2...2.7 GHz EN/IEC 61000-4-3 || 10 V/m 80...2000 MHz EN/IEC 61000-4-3
    • Standards : IEC 61131-2 || UL 508 || CSA C22.2 No 142 || CSA C22.2 No 213
    • Storage Altitude : 0-3000 m
    • Ambient Air Temperature For Operation : -10-55 °C without derating horizontal installation) || 55-60 °C with derating factor horizontal installation) || -10-50 °C vertical installation)
    • Vibration Resistance : 1 gn 8.4-150 Hz DIN rail || 3.5 mm 5-8.4 Hz DIN rail
    • Shock Resistance : 15 gn 11 ms
    • Disturbance Radiated/Conducted : CISPR 11
    • Electromagnetic Compatibility : EN/IEC 61000-4-6
    • Surge Withstand : 0.5 kV differential mode EN/IEC 61000-4-5 || 1 kV common mode EN/IEC 61000-4-5
    • Ambient Air Temperature For Storage : -25-70 °C
    • Relative Humidity : 5-95 % without condensation
    • Resistance To Electrostatic Discharge : 4 kV on contact EN/IEC 61000-4-2 || 8 kV in air EN/IEC 61000-4-2
    • Resistance To Fast Transients : 1 kV EN/IEC 61000-4-4 I/O) || 1 kV EN/IEC 61000-4-4 shielded cable) || 2 kV EN/IEC 61000-4-4 power lines)
    • Operating Altitude : 0...6561.68 ft (0...2000 m)
  • Specifications
    • Range Of Product : Modicon TM5
    • Product Or Component Type : power distribution module
    • Product Specific Application : supply 24 V DC I/O modules
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1511026EN
    • Sustainable Offer Status : Green Premium product
    • Pvc Free : Yes
    • Toxic Heavy Metal Free : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • China Rohs Regulation : X
    • Circularity Profile : ENVEOLI1511026EN
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
  • Complementary
    • [Us] Rated Supply Voltage : 24 V
    • Network Type : DC
    • Marking : CE
    • Power Supply Output Current : 10-10 A I/O power segment
    • Net Weight : 0.061 kg
    • Current Consumption : <= 25 mA 24 V DC
    • Maximum Power Dissipation In W : 0.8 W
    • Color : Red
    • Short-Circuit Protection : 10 A external fuse
    • Range Compatibility : Modicon M258 || Modicon LMC058
    • Product Compatibility : motion controller || logic controller
