SQUARE D

Panelboard interior, NQ, main lugs, 600A, Cu bus, 30 pole spaces, 1 phase, 3 wire, 240 VAC, 48 VDC

PNLBD INT NQ 600A MLO 30 CKT 1

SQDNQ30L6C NQ30L6C 785901498285
1971.56 / EACH
  • Amperage: 600 A
  • Country of Origin: USA
  • Height: 1143.00 mm, 45 in
  • Number of Phases: 1
  • Standard: CSA, UL
  • Voltage: 240 V, 48 V
  • Warranty Length: 18 mth
  • Width: 10.44 in, 265.18 mm
NQ Panelboard interiors can be used for applications such as commercial buildings, industrial buildings, stadiums, and offices. NQ Panelboards are versatile panelboards that feature a wide selection of circuit breakers, accessories, and ready to install kits. NQ Panelboard interiors are field convertible to top or bottom feed. NQ Panelboards are convertible from main lug to main breaker. NQ Panelboards provide 200% rated neutrals for nonlinear loads. Some factory installed options are split bus, lighting contactors, compression lugs, surge protection devices, and phenolic nameplates. This interior provides protection for your commercial and industrial applications. The main lugs are rated at 600A, 240 VAC single phase or 48 VDC. Interior has an interrupt current rating of up to 65 kA. This interior is for a 3 wire system with 30 spaces and has a copper bus bar. Interior is for QOB, QOBVH and QHB branch circuit breakers. Lug connections will accept two 1/0 AWG to 750 kcmil copper or aluminum wire. Interior is 45 inches tall and 10.44 inches wide. This NQ panelboard interior is UL listed and CSA certified.
  • Product Description
  • Specifications
NQ Panelboard interiors can be used for applications such as commercial buildings, industrial buildings, stadiums, and offices. NQ Panelboards are versatile panelboards that feature a wide selection of circuit breakers, accessories, and ready to install kits. NQ Panelboard interiors are field convertible to top or bottom feed. NQ Panelboards are convertible from main lug to main breaker. NQ Panelboards provide 200% rated neutrals for nonlinear loads. Some factory installed options are split bus, lighting contactors, compression lugs, surge protection devices, and phenolic nameplates. This interior provides protection for your commercial and industrial applications. The main lugs are rated at 600A, 240 VAC single phase or 48 VDC. Interior has an interrupt current rating of up to 65 kA. This interior is for a 3 wire system with 30 spaces and has a copper bus bar. Interior is for QOB, QOBVH and QHB branch circuit breakers. Lug connections will accept two 1/0 AWG to 750 kcmil copper or aluminum wire. Interior is 45 inches tall and 10.44 inches wide. This NQ panelboard interior is UL listed and CSA certified.
  • Environment
    • Standards : UL || CSA
  • Main
    • Busbar Material : Copper
    • Branch Circuit Breaker Type : QOB || QOB-VH || QHB
    • Panelboard Type : Main lugs
  • Ordering And Shipping Details
    • Category : 09151 - NQ RTA PANELBOARDS
    • Country Of Origin : US
    • GTIN : 00785901498285
    • Returnability : Yes
    • Nbr. Of Units In Pkg. : 1
    • Discount Schedule : PE1A
  • Complementary
    • Enclosure Nominal Width : 20 in (508.00 mm)
    • Height : 45 in (1143.00 mm)
    • Iu Rated Interrupted Current : 10 kA || 22 kA || 65 kA
    • Enclosure Nominal Height : 62 in (1574.80 mm)
    • Voltage Rating : 240 V AC || 48 V DC
    • Tightening Torque : 274.99…300.04 lbf.in (31.07…33.90 N.m) 0.08…0.59 in² (53.48…380 mm²) AWG 1/0...750 kcmil) || 274.99…300.04 lbf.in (31.07…33.90 N.m) 0.08…0.27 in² (53.48…177.3 mm²) AWG 1/0...350 kcmil) || 549.98 lbf.in (62.14 N.m) 0.08…0.59 in² (53.48…380 mm²) AWG 1/0...750 kcmil) || 549.98 lbf.in (62.14 N.m) 0.08…0.24 in² (53.48…152 mm²) AWG 1/0...300 kcmil) || 375.01 lbf.in (42.37 N.m) 0.08…0.59 in² (53.48…380 mm²) AWG 1/0...750 kcmil) || 375.01 lbf.in (42.37 N.m) 0.08…0.24 in² (53.48…152 mm²) AWG 1/0...300 kcmil)
    • Wiring Configuration : 3-wire
    • Number Of Phases : 1 phase
    • In Rated Current : 600 A
    • Number Of Spaces : 30
    • Enclosure Nominal Depth : 5.75 in (146.05 mm) NEMA 1 || 6.5 in (165.10 mm) NEMA 3R/5/12
    • Width : 10.44 in (265.18 mm)
  • Offer Sustainability
    • Mercury Free : Yes
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Bisphenol A (BPA), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • EU RoHs Directive : Compliant
    • REACh Free Of SVHC : Yes
    • Green Premium Status : Green Premium product
  • Contractual Warranty
    • Warranty : 18 months
