SQUARE D

Illuminated push-button, Harmony 9001K, metal, mushroom 41mm, red, 30mm, 3 positions, return to center, LED red, 24-28V, 1 NC late + 1 NC

PUSH BUTTON 600VAC 10A 30MM T-

SQD9001KR8P35LRRH25 9001KR8P35LRRH25 785901289739
308.69 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Illuminated push-button, Harmony 9001K, metal, mushroom 41mm, red, 30mm, 3 positions, return to center, LED red, 24-28V, 1 NC late + 1 NC-1
  • Bezel Material: Metal
  • Country of Origin: Mexico
  • Light Source: LED
  • Warranty Length: 18 mth
30 mm heavy duty chromium plated metal push buttons, selector switches, pilot lights, and specialty operators
QTY
  • Features
  • Specifications
  • Ie Rated Operational Current
    • 10 A, AC-15
    • 10 A, DC-13
  • Product Certifications
    • CSA LR 25490 class 3211 03
    • NEMA
    • UL listed file E42259 CCN NKCR
    • CE
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Accessories
    • 9001KN201
    • 9001KN202
  • Physical Attributes
    • Cap Operator Or Lens Color : red
    • Light Source Color : red
    • Size : 30 mm
  • Complementary Attributes
    • Us Rated Supply Voltage : 24...28 V
  • Important Information Attributes
    • Local Data Status : Publishable
    • Local Publishable Date : 2024-09-09
    • Etim 10 : EC001028
    • Legacy Weee Scope : In
    • Weee Product Category : 5
    • Scope Perimeter : Outside of Europe
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • Rohs Eur In Scope : No
    • Rohs Eur Status : Compliant with Exemptions
    • Rohs Eur Conformity Date : 1930
    • Rohs Eur Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • China Rohs In Scope : Yes
    • China Rohs Label : 6
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • Wd Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Bezel Material : metal
    • Bulb Base : BA 9s
    • Cap Operator Or Lens Color : red
    • Contact Operation : late-break
    • Contacts Type And Composition : 1 NC late break + 1 NC
    • Device Short Name : K
    • Light Block Supply : without supply
    • Light Source : LED
    • Light Source Color : red
    • Mounting Diameter : 30 mm
    • Operator Additional Information : screw-on plastic
    • Operator Position Information : 3 positions
    • Operator Profile : mushroom Ø 41 mm
    • Package Weight Lbs : 226.796 g
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : illuminated push-button
    • Range Of Product : Harmony 9001K
    • Returnability : No
    • Sustainable Packaging : Yes
    • Type Of Operator : pull : spring return, center : stay put, push : spring return
    • Relationshiptype : Compatible relationship
  • General Attributes
    • Product Or Component Type : illuminated push-button
    • Range Of Product : Harmony 9001K
  • ETIM
    • ETIM 8 : EC001028
    • ETIM 9 : EC001028
  • Environment Attributes
    • Take Back : No
    • China Rohs Regulation : X
    • Mercury Free : Yes
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Nema Degree Of Protection : NEMA 1/2/3/3R/4/6/12/13
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : Mexico
  • Overview Attributes
    • Device Presentation : complete product
