SQUARE D

Pilot light, Harmony 9001SK, plastic, polycarbonate, fresnel, red, 30mm, LED red, 208-220V

PILOT LIGHT 220VAC 30MM SK +OP

SQD9001SKP3LRR31 9001SKP3LRR31 785901325321
193.29 / EACH
http://schema.org/OutOfStock
This single component pilot light provides clear visual feedback on the status of your machines It is clearly distinguishable visually at a distance due to clear colors and illumination via integral LED, enabling complex machine statuses to be read at a glance It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections High performance International standards & certifications (Marine ABS certification, IP66, Type 1, 2, 3, 3R, 4, 4X, 12 and 13)
QTY
  • Specifications
  • Specifications
    • Range Of Product : Harmony 9001SK
    • Light Block Supply : direct 208...220 V AC 50/60 Hz
    • Product Or Component Type : pilot light
    • Lens Type : fresnel plastic
    • Device Short Name : 9001SK
  • Contractual warranty
    • Warranty : 18 months
  • Complementary
    • Connections - Terminals : screw clamp terminals, 1 x 0.22...2 x 1.5 mm² EN/IEC 60947-1
    • [Us] Rated Supply Voltage : 208...220 V AC 50/60 Hz
    • Light Source : Red LED
    • [Ui] Rated Insulation Voltage : 250 V 2)EN/IEC 60947-1
    • Bezel Material : plastic
    • Mounting Diameter : 30 mm
    • Operating Position : any position
    • [Ith] Conventional Free Air Thermal Current : 10 A
    • Short-Circuit Protection : 10 A cartridge fuse EN/IEC 60947-5-1
    • Shape Of Signaling Unit Head : round
    • Cap/Operator Or Lens Colour : red
    • Tightening Torque : 0.8-0.8 N.m EN/IEC 60947-1
    • Cad Overall Width : 54 mm
    • Cad Overall Depth : 42 mm
    • Net Weight : 0.181 kg
    • Shape Of Screw Head : cross slotted
    • [Uimp] Rated Impulse Withstand Voltage : 2.5 kV EN/IEC 60947-1
    • Cad Overall Height : 70 mm
    • Bulb Base : BA 9s
  • Offer Sustainability
    • China Rohs Regulation : X
    • Circularity Profile : ENVEOLI1710019EN
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1710019EN
    • Sustainable Offer Status : Green Premium product
    • Toxic Heavy Metal Free : Yes
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Reach Free Of Svhc : Yes
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
  • Environment
    • Product Certifications : UL 508 || NEMA
    • Ambient Air Temperature For Operation : -25-70 °C
    • Ambient Air Temperature For Storage : -40-70 °C
    • Standards : JIS C 852 || EN/IEC 60947-1 || UL 508 || JIS C8201-5-1 || EN/IEC 60947-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-4 || JIS C8201-1
    • Nema Degree Of Protection : NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 4X
    • Electrical Shock Protection Class : class II IEC 61140
    • Shock Resistance : 50 gn IEC 60068-2-27
    • Vibration Resistance : 7 gn 2-500 Hz)IEC 60068-2-6
    • Protective Treatment : TC
    • Ip Degree Of Protection : IP66 IEC 60529
