SQUARE D

PILOT LIGHT 120VAC 30MM TYPE K +OPTIONS

PILOT LIGHT 120VAC 30MM TYPE K

SQD9001KP1LGG31 9001KP1LGG31 785901575528
143.97 / EACH
  • Bezel Material: Chromium Plated Metal
  • Certifications: NEMA, UL 508
  • Country of Origin: Mexico
  • Lens Type: Domed Plastic
  • Standard: CSA C22.2 No 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C 852, JIS C8201-1, JIS C8201-5-1, UL 508
  • Warranty Length: 18 mth
  • Weight: 0.21 kg, 0.46 lb
This single component pilot light provides clear visual feedback on the status of your machines It is clearly distinguishable visually at a distance due to clear colors and illumination via integral green LED, enabling complex machine statuses to be read at a glance It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections It weights 0.14 kg High performance International standards & certifications (Marine ABS certification, IP66, Type 1, 2, 3, 3R, 4, 12 and 13)
  • Product Description
  • Specifications
This single component pilot light provides clear visual feedback on the status of your machines It is clearly distinguishable visually at a distance due to clear colors and illumination via integral green LED, enabling complex machine statuses to be read at a glance It is impact resistant, dust resistant, water resistant and vibration resistant thanks to its IP66, making it ideal for operation in harsh environments It is easily installed into a standard 30mm diameter panel cut-outs and connected with simple screw-clamp connections It weights 0.14 kg High performance International standards & certifications (Marine ABS certification, IP66, Type 1, 2, 3, 3R, 4, 12 and 13)
  • Ordering And Shipping Details
    • Discount Schedule : CS1
    • GTIN : 00785901575528
    • Returnability : Yes
    • Country Of Origin : MX
    • Category : 21426 - 9001 K (NOT KA,KM,KX)
  • Complementary
    • Bulb Base : BA 9s
    • Cad Overall Height : 2.76 in (70 mm)
    • Cap/Operator Or Lens Colour : Green
    • Tightening Torque : 7.08 lbf.in (0.8 N.m) IEC 60947-1
    • Lens Type : Domed plastic
    • Product Weight : 0.46 lb(US) (0.21 kg)
    • Short-Circuit Protection : 10 A cartridge fuse IEC 60947-5-1
    • Connections - Terminals : Screw clamp terminals, 1 x 0.22...2 x 1.5 mm² IEC 60947-1
    • Shape Of Screw Head : Cross slotted
    • Light Block Supply : Direct 110...120 V AC 50/60 Hz
    • Shape Of Signaling Unit Head : Round
    • Cad Overall Width : 2.13 in (54 mm)
    • Mounting Diameter : 1.18 in (30 mm)
    • Ith Cnvtl Free Air Therm Crrt : 10 A
    • Light Source : Green LED
    • Uimp Rated Imp Wstd Voltage : 2.5 kV IEC 60947-1
    • Ui Rated Insulation Voltage : 250 V 2)IEC 60947-1
    • Operating Position : Any position
    • Cad Overall Depth : 1.65 in (42 mm)
    • Bezel Material : Chromium plated metal
  • Contractual Warranty
    • Warranty : 18 months
  • Environment
    • IP Degree Of Protection : IP66 IEC 60529
    • Nema Degree Of Protection : NEMA 1 || NEMA 12 || NEMA 13 || NEMA 2 || NEMA 3 || NEMA 3R || NEMA 4 || NEMA 6
    • Standards : EN/IEC 60947-5-4 || EN/IEC 60947-5-1 || JIS C8201-5-1 || EN/IEC 60947-1 || CSA C22.2 No 14 || UL 508 || JIS C 852 || JIS C8201-1
    • Overvoltage Category : Class II conforming to IEC 61140
    • Vibration Resistance : 7 gn 2…500 Hz)IEC 60068-2-6
    • Product Certifications : NEMA || UL 508
    • Protective Treatment : TC
    • Ambient Air Temp For Op : -13…158 °F (-25…70 °C)
    • Shock Resistance : 50 gn IEC 60068-2-27
    • Ambient Air Temp For Storage : -40…158 °F (-40…70 °C)
  • Main
    • Product Or Component Type : Pilot light
    • Range Of Product : Harmony 9001K
    • Device Short Name : 9001K
  • Offer Sustainability
    • Mercury Free : Yes
    • EU RoHs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • WEEE : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • Green Premium Status : Green Premium product
