• Specifications
  • Safety Level : SIL 3 EN/IEC 61508
  • Continuous Power : 150 W 115 V
  • Output Current 3S Peak 2 : 3 A 115 V
  • Shock Resistance : 15 gn 11 ms EN/IEC 60028-2-27
  • [Us] Rated Supply Voltage : 100...120 V - 15...10 % || 200...240 V - 15...10 %
  • Continuous Output Current : 1.5 A 8 kHz
  • Discrete Output Type : logic DO)24 V DC
  • Ip Degree Of Protection : IP20 EN/IEC 60529
  • Switching Frequency 2 : 8 kHz
  • Vibration Resistance : 1 gn 13-150 Hz)EN/IEC 60068-2-6
  • Network Frequency : 47.5...63 Hz
  • Output Current 3S Peak : 3 A 115 V 5 s
  • Tightening Torque : CN8 0.5-0.5 N.m
  • Compatibility Code : LXM32S
  • Switching Frequency 3 : 8 kHz
  • Braking Current : 50 mA
  • Discrete Output Voltage : <= 30 V DC
  • Physical Interface : 2-wire RS485 multidrop Modbus
  • Transmission Rate : 9600, 19200, 38400 bps 40-40 m Modbus
  • Relative Humidity : Class 3K3 (5 to 85 %) without condensation IEC 60721-3-3
  • Supply Voltage Limits : 85-132 V || 170-264 V
  • Electrical Connection : terminal 3 mm², AWG 12 CN8)
  • Supply Frequency : 50/60 Hz - 5...5 %
  • Electromagnetic Compatibility : conducted EMC EN 55011 class A group 1
  • Discrete Output Logic : positive or negative DO)EN/IEC 61131-2
  • Maximum Width : 68 mm
  • Device Short Name : LXM32S
  • Drive Voltage Drop Coefficient : 0.9
  • Nominal Power : 0.15 kW 115 V 8 kHz || 0.3 kW 230 V
  • Supply Voltage Description : single phase 115 V
  • Field Weakening : false
  • Continuous Output Current 3 : 1.5 A
  • Response Time On Output : 250 µs DO)discrete
  • Safety Function : STO (safe torque off), Integrated
  • Ambient Air Temperature For Operation : 0-50 °C UL
  • Emc Filter Compatibility : type 020
  • Line Current : 2.6 A 85 % 115 V, with external line choke 5 mH || 3.4 A 100 % 230 V, with external line choke 5 mH || 2.9 A 173 % 115 V, without line choke
  • Discrete Input Number : 2 capture
  • Product Certifications : CSA
  • Number Of Addresses : 1-247 Modbus
  • Communication Interface : Modbus, Integrated || SERCOS III, Integrated
  • Continuous Output Current 2 : 1.5 A
  • Response Time : <= 5 ms compliment of STO_A, compliment of STO_B
  • Sampling Duration : 0.25 ms
  • Switching Frequency : 8 kHz
  • Number Of Inputs/Outputs : 4 DI + 2 CI + 3 DO
  • Range Of Product : Lexium 32
  • Product Compatibility : servo motor BSH 55 mm, 1
  • Discrete Output Number : 3
  • Status Led : servo drive voltage 1 LED Red)
  • Phase : single phase
  • Output Voltage : <= power supply voltage
  • Discrete Input Voltage : 24 V DC capture
  • Network Number Of Phases : 1
  • Discrete Input Logic : positive compliment of STO_A, compliment of STO_B)< 5 V > 15 V EN/IEC 61131-2 type 1
  • Warranty : 18 months
  • Overvoltage Category : III
  • Standards : EN/IEC 61800-3
  • Operating Position : vertical +/- 10 degree
  • Output Current 3S Peak 3 : 3 A 115 V
  • Format Of The Drive : book
  • Connector Type : RJ45 (labelled CN7) Modbus
  • Discrete Input Type : capture CAP
  • Maximum Leakage Current : 30 mA
  • Net Weight : 1.7 kg
  • Signalling Function : display of faults 7 segments
  • Communication Iinterface : SERCOS III
  • Operating Altitude : <= 3280.84 ft (1000 m) without derating
  • Ambient Air Temperature For Storage : -25-70 °C
  • Environmental Characteristic : classes 3C1 IEC 60721-3-3
  • Emc Filter : integrated
  • Marking : CE
  • Maximum Height : 270 mm
  • Contact Bounce Time : <= 1 ms compliment of STO_A, compliment of STO_B
  • Maximum Depth : 237 mm
  • Pollution Degree : 2 EN/IEC 61800-5-1
  • Electrical Isolation : between power and control
  • Product Or Component Type : motion servo drive
  • Type Of Cable : single-strand IEC cable 50-50 °C) copper 90 °C XLPE/EPR
  • Type Of Cooling : natural convection
