Motion controller LMC101 for robot - 80 license points included

MOTION CONTROLLER LMC101 FOR R

SQDLMC101CAA150RC LMC101CAA150RC SQDLMC101CAA150RC
0.00 / EA
http://schema.org/OutOfStock
Mayer-DDS-Motion controller LMC101 for robot - 80 license points included-1
  • Country of Origin: France
QTY
  • Features
  • Specifications
  • Memory Type
    • 512 MB RAM DDR2
    • 128 kB NVRAM
  • US Rated Supply Voltage
    • 24 V DC
  • Discrete Input Current
    • 4 mA digital input
  • Anti Bounce Filtering
    • 100 µs...4.29 s configurable digital input
    • 100 µs...4.29 s configurable touch probe input
    • 100 µs...4.29 s configurable to
  • IP Degree Of Protection
    • IP20IEC 60529
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Type Of License
    • 80 license point(s)
  • Discrete Output Number
    • 8 digital output
  • Supply
    • power supply 24 VDC
  • Vibration Resistance
    • 3.5 mm 5-8.4 Hz
    • 10 m/s² 8.4-150 Hz
  • Persona Type Names
    • End User
    • Original Equipment Manufacturer
  • Discrete Output Current
    • 500 mA digital output
  • Relative Humidity
    • 5-95 % without condensation
  • Persona Type Ids
    • EU
    • OM
  • Programming Language
    • ST (structured text)
    • LD (ladder)
    • IL (instruction list)
    • FBD (function block diagram)
    • SFC (sequential function chart)
    • CFC (continuous function chart)
  • Integrated Connection Type
    • 2 Ethernet port RJ45 Sercos
    • 1 Ethernet port RJ45 Ethernet 10/100BASE-T, FTP/HTTP
    • 1 Ethernet port RJ45 Ethernet 10/100
  • Shock Resistance
    • 150 m/s² 6 ms operation)IEC 60721-3-3
  • Discrete Input Number
    • 8 digital input IEC 61131-2 Type 1
    • 4 touch probe input IEC 61131-2 Type 1
  • Complementary Attributes
    • Maximum Cable Distance Between Devices : <50 m
    • Maximum Leakage Current : 0.5 mA
  • Important Information Attributes
    • Local Data Status : Publishable
    • Local Publishable Date : 7/9/2025
    • Device Type : PLC System - PLC CPU
    • Serviceability : Yes
    • Traceability : Yes
    • Field Service Division : IDIBS
    • Average Life Duration : 20 year(s)
    • Legacy WEEE Scope : Out
    • Scope Perimeter : At least in Europe
    • EOLI Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI1403026EN
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Conformity Date : 1901
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : Yes
    • China ROHS Label : 5
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Dangerous Goods Code : LITHIUM METAL BATTERIES IN EQUIP. BUTTON CELL-BAT EXEMPT
    • Tier Id : 3
    • Tier : 3
    • Function Option Id : ADVANCED
    • Function Option : Advanced
    • Market Segmentation Id : INDUSTRIAL
    • Market Segmentation : Industrial
    • Package Weight Lbs : 2.2 kg
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : Motion controller
    • Range Of Product : PacDrive 3
    • Returnability : Yes
    • Sustainable Packaging : No
    • Relationship Type : Compatible relationship
    • Pep Code : ENVPEP1403026EN
    • Warranty In Months : 18
  • General Attributes
    • Product Or Component Type : Motion controller
    • Range Of Product : PacDrive 3
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=368046153&lang=en-us
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0%
    • China ROHS Regulation : X
    • Mercury Free : Yes
    • Ambient Air Temperature For Operation : 5-55 °C
    • Circularity Profile : ENVEOLI1403026EN
    • Environmental Disclosure : ENVPEP1403026EN
    • EU ROHS Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP1403026EN
  • Input Attributes
    • Discrete Input Voltage Type : DC
  • Specifications
    • Country of Origin : France
