Molded Case Circuit Breaker 600V 175A

Molded Case Circuit Breaker 600V 175A

SQDJJF36175 JJF36175 785901602491
4710.31 / EACH
  • Country of Origin: USA
  • Mounting Type: Unit Mount
  • Number of Poles: 3
  • Package Weight: 4.5 lb
  • Voltage: 250 V, 600 V
  • Warranty Length: 18 mth
The PowerPact H, J, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. L-frame circuit breakers are available with Micrologic electronic trip units only.
  • Product Description
  • Features
  • Specifications
The PowerPact H, J, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. L-frame circuit breakers are available with Micrologic electronic trip units only.
  • Educational Campuses
  • Industrial Markets
  • Oil & Gas
  • Healthcare Facilities
  • Data Centers
  • OEM Commercial
  • Commercial Buildings
  • Construction
  • Marine
  • Industrial Buildings
  • Worldwide availability with unique global part numbers
  • Flexible and simple offer, with proven performance
  • Direct access to energy metering and energy efficiency thanks to the Micrologic control units
  • Offer Sustainability
    • Product End Of Life Instructions : Need no specific recycling operations
    • Sustainable Offer Status : Green Premium product
    • Product Environmental Profile : Available
    • RoHS (Date Code: YYWW) : Compliant  - since  0832  -  Schneider Electric declaration of conformity
  • Contractual Warranty
    • Warranty Period : 18 months
  • Ordering and Shipping Details
    • Country Of Origin : US
    • Category : 01115 - HG,HJ,JG,JJ UNIT MT BREAKER/SWITCH
    • GTIN : 00785901602491
    • Discount Schedule : DE2
    • Number Of Units In Package : 1
    • Returnability : Y
    • Package Weight(Lbs) : 4.5
  • Environment
    • Product Certifications : CCC || CE || UL listed || CSA || IEC
    • Ambient Air Temperature For Operation : 104 °F (40 °C)
  • Complementary
    • Number Of Poles : 3
    • Magnetic Hold Current : 875 A
    • Magnetic Tripping Current : 1750 A
    • Line Rated Current : 175 A
    • System Voltage : 250 V DC || 600 V AC
    • Continuous Current Rating : 80 %
    • Breaking Capacity : 20 kA 250 V DC || 100 kA 240 V AC || 65 kA 480 V AC || 25 kA 600 V AC
    • Electrical Connection : Busbar connection load || Busbar connection line
    • Mounting Mode : Unit mount
    • Depth : 5 in
    • Width : 4.12 in
    • Height : 7.52 in
    • Poles Description : 3P
  • Main
    • Breaking Capacity Code : J
    • Product Or Component Type : Circuit breaker
    • Trip Unit Technology : Thermal-magnetic
    • Range Of Product : PowerPact J
