Mini circuit breaker, QOU, 50A, 2 pole, 120/240VAC, 10kA, bulk pack

Mini circuit breaker, QOU, 50A, 2 pole, 120/240VAC, 10kA, bulk pack

SQDQOU250B QOU250B 785901121084
72.22 / EACH
  • Certifications: CSA, IEC, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.95 in
  • Height: 4.05 in
  • Line Rated Current: 50 A
  • Mounting Type: Unit Mount
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 1.5 in
QO™ and QOU Miniature Circuit Breakers, QOU250B, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Distributes in a Bulk packing.
  • Product Description
  • Specifications
QO™ and QOU Miniature Circuit Breakers, QOU250B, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Distributes in a Bulk packing.
  • Type Of Packing : bulk
  • Maximum Height : 4.05 in
  • Mounting Mode : unit mount
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC || 48 V DC
  • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 120 V AC || 5 kA 48 V DC
  • Electrical Connection : slotted box lugs, line side || slotted box lugs, load side
  • Range Of Product : QOU
  • Warranty : 18 months
  • Maximum Width : 1.5 in
  • Awg Gauge : AWG 14...AWG 2 aluminium/copper
  • Product Or Component Type : miniature circuit-breaker
  • Line Rated Current : 50 A
  • Circuit Breaker Application : HACR and Switching Duty rated
  • Short-Circuit Current : 10 kA || 5 kA
  • Maximum Depth : 2.95 in
  • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
  • Product Certifications : UL Listed || IEC || CSA
  • Poles Description : 2P
  • Circuit Breaker Type : standard
