Mini circuit breaker, QOU, 35A, 3 pole, 240 VAC, 10kA, bulk pack

Mini circuit breaker, QOU, 35A, 3 pole, 240 VAC, 10kA, bulk pack

SQDQOU330B QOU330B 785901121169
241.60 / EACH
  • Certifications: CSA, IEC, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.95 in
  • Height: 4.05 in
  • Line Rated Current: 30 A
  • Mounting Type: Unit Mount
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 2.25 in
QO™ and QOU Miniature Circuit Breakers, QOU330B, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Distributes in a Bulk packing.
  • Product Description
  • Specifications
QO™ and QOU Miniature Circuit Breakers, QOU330B, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Distributes in a Bulk packing.
  • Maximum Width : 2.25 in
  • [Ue] Rated Operational Voltage : 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
  • Range Of Product : QOU
  • Product Certifications : CSA || UL Listed || IEC
  • Circuit Breaker Application : HACR and Switching Duty rated
  • Awg Gauge : AWG 14...AWG 2 aluminium/copper
  • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 240 V AC || 10 kA 120 V AC || 5 kA 48 V DC
  • Mounting Mode : unit mount
  • Maximum Depth : 2.95 in
  • Poles Description : 3P
  • Electrical Connection : slotted box lugs, line side || slotted box lugs, load side
  • Warranty : 18 months
  • Circuit Breaker Type : standard
  • Type Of Packing : bulk
  • Maximum Height : 4.05 in
  • Line Rated Current : 30 A
  • Product Or Component Type : miniature circuit-breaker
  • Short-Circuit Current : 10 kA || 5 kA
  • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
