Mini circuit breaker, QOU, 35A, 2 pole, 120/240 VAC, 10kA, field reversible lugs

Mini circuit breaker, QOU, 35A, 2 pole, 120/240 VAC, 10kA, field reversible lugs

SQDQOUR235 QOUR235 785901224778
89.42 / EACH
  • Certifications: CSA, IEC, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.95 in
  • Height: 4.05 in
  • Line Rated Current: 35 A
  • Mounting Type: Unit Mount
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 1.5 in
QO™ and QOU Miniature Circuit Breakers, QOUR235, is ideal for OEM applications. Equipped with Rotated fixing lug QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers provide a means to manually open a circuit.
  • Product Description
  • Specifications
QO™ and QOU Miniature Circuit Breakers, QOUR235, is ideal for OEM applications. Equipped with Rotated fixing lug QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers provide a means to manually open a circuit.
  • Awg Gauge : AWG 14...AWG 2 aluminium/copper
  • Mounting Mode : unit mount
  • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 120 V AC || 5 kA 48 V DC
  • Accessory / Separate Part Type : rotatable fixing lug
  • Maximum Depth : 2.95 in
  • Product Or Component Type : miniature circuit-breaker
  • Circuit Breaker Type : standard
  • Line Rated Current : 35 A
  • Circuit Breaker Application : HACR and Switching Duty rated
  • Range Of Product : QOU
  • Maximum Height : 4.05 in
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC || 48 V DC
  • Electrical Connection : slotted box lugs, line side || slotted box lugs, load side
  • Poles Description : 2P
  • Maximum Width : 1.5 in
  • Warranty : 18 months
  • Product Certifications : UL Listed || IEC || CSA
  • Short-Circuit Current : 10 kA || 5 kA
  • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
