Mini circuit breaker, QOU, 30A, 3 pole, 240 VAC, 10kA, field reversible lugs

Mini circuit breaker, QOU, 30A, 3 pole, 240 VAC, 10kA, field reversible lugs

SQDQOUR330 QOUR330 785901079408
294.04 / EACH
  • Certifications: CSA, IEC, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.95 in
  • Height: 4.05 in
  • Line Rated Current: 30 A
  • Mounting Type: Unit Mount
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 2.25 in
  • Specifications
  • Short-Circuit Current : 10 kA || 5 kA
  • Circuit Breaker Application : HACR and Switching Duty rated
  • Warranty : 18 months
  • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 240 V AC || 10 kA 120 V AC || 5 kA 48 V DC
  • Poles Description : 3P
  • Line Rated Current : 30 A
  • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
  • [Ue] Rated Operational Voltage : 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
  • Electrical Connection : slotted box lugs, line side || slotted box lugs, load side
  • Maximum Depth : 2.95 in
  • Accessory / Separate Part Type : rotatable fixing lug
  • Product Or Component Type : miniature circuit-breaker
  • Circuit Breaker Type : standard
  • Range Of Product : QOU
  • Awg Gauge : AWG 14...AWG 2 aluminium/copper
  • Maximum Width : 2.25 in
  • Maximum Height : 4.05 in
  • Mounting Mode : unit mount
  • Product Certifications : UL Listed || CSA || IEC
