SQUARE D

Mini circuit breaker, QOU, 20A, 2 pole, 120/240 VAC, 10kA, field reversible lugs, ring terminal, China certified

MINIATURE CIRCUIT BREAKER 120/

SQDQOUR2205283CCC QOUR2205283CCC 785901918141
129.33 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QOU, 20A, 2 pole, 120/240 VAC, 10kA, field reversible lugs, ring terminal, China certified-1
  • Depth: 2.95 in
  • Warranty Length: 18 mth
QOU Miniature Molded Case Circuit Breakers are intended for use in residential and commercial applications. They are used for overcurrent protection and switching on both AC and DC electrical systems. These breakers provide a means to manually open a circuit using the interally magnetic strips. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This two pole QOU miniature circuit breaker is rated as 20A, 240VAC. This circuit breaker provides 10 kA breaking capacity. QOU circuit breakers have been verified to adhere to their datasheet specifications by UL and CSA. Equipped with ring terminal connectors to facilitate secure and reliable wire terminations. Ideal for applications requiring bolted connections and enhanced vibration resistance. Features field-reversible lugs, allowing flexible installation configurations to accommodate various wiring orientations and panel layouts.
QTY
  • Product Description
  • Features
  • Specifications
QOU Miniature Molded Case Circuit Breakers are intended for use in residential and commercial applications. They are used for overcurrent protection and switching on both AC and DC electrical systems. These breakers provide a means to manually open a circuit using the interally magnetic strips. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. These QOU miniature circuit breakers can be DIN rail mounted, surface mounted or flush mounted using mounting feet. This two pole QOU miniature circuit breaker is rated as 20A, 240VAC. This circuit breaker provides 10 kA breaking capacity. QOU circuit breakers have been verified to adhere to their datasheet specifications by UL and CSA. Equipped with ring terminal connectors to facilitate secure and reliable wire terminations. Ideal for applications requiring bolted connections and enhanced vibration resistance. Features field-reversible lugs, allowing flexible installation configurations to accommodate various wiring orientations and panel layouts.
  • Features
    • Ideal for OEM applications and have the Square D’s unique Visi-Trip Indicator feature.
    • Can be DIN rail-mounted, surface-mounted, or flush-mounted.
    • Simple design and clear instructions help you install correctly.
    • Single handle with internal common trip.
    • Field-installable quick connectors.
  • Conformance Attributes
    • Product Certifications : IEC, CSA, CCC, UL Listed
  • Complementary Attributes
    • Line Rated Current : 20 A
  • Important Information Attributes
    • Persona Type Ids : EU, OM
    • Persona Type Names : End User, Original Equipment Manufacturer
    • Electrical Connection : ring tongue, line side, ring tongue, load side
    • Ue Rated Operational Voltage2 : 120/240 V AC, 120 V AC, 48 V DC
    • Carbon Footprint Of The Distribution Phase A4 : 0.0503306245, 0.1 kg CO2 eq.
    • Carbon Footprint Of The End Of Life Phase C1 To C4 : 0.1 kg CO2 eq., 0.0713111781
    • Carbon Footprint Of The Installation Phase A5 : 0.0000974414, 0 kg CO2 eq.
    • Carbon Footprint Of The Manufacturing Phase A1 To A3 : 2 kg CO2 eq., 2.2793776988
    • Carbon Footprint Of The Use Phase B2 B3 B4 B6 : 17 kg CO2 eq., 17.3042434783
    • Ue Rated Operational Voltage5 : 120/240 V AC, 120 V AC, 48 V DC
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-18
    • Device Type : LV equipment - Low voltage circuit breaker
    • Serviceability : No
    • Traceability : No
    • Field Service Division : PPIBS
    • Average Life Duration : 15 year(s)
    • Legacy WEEE Scope : In
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant
    • ROHS EUR Full Compliance Status : Compliant
    • ROHS EUR Full Compliance Status Id : COMPLIANT
    • China ROHS In Scope : No
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : N
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : COMMERCIAL
    • Market Segmentation : Commercial
    • H And D Domain : Safety
    • H And D Subrange : INDUS
    • H And D Enrichment Assignment : no
    • H And D Enrichment Function : MCB
    • H And D Enrichment Class 3 : Circuit Breakers
    • H And D Enrichment Class 4 : MCB UL 2P
    • AWG Gauge : AWG 14...AWG 2 aluminium/copper
    • Circuit Breaker Application : HACR rated
    • Circuit Breaker Type : standard
    • Energy Efficiency Optimized : False
    • Halogen Free Status : Halogen free product
    • Mounting Mode : unit mount
    • Package Weight Lbs : 390.089 g
    • Poles Description : 2P
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : miniature circuit-breaker
    • Range Of Product : QOU
    • Returnability : No
    • Short Circuit Current : 10 kA
    • Sustainable Packaging : No
    • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
    • Total Lifecycle Carbon Footprint : 20 kg CO2 eq.
    • Accessory Separate Part Type2 : rotatable fixing lug
    • Medium Desc : Mini circuit breaker, QOU, 20A, 2 pole, 120/240 VAC, 10kA, field reversible lugs, ring terminal, China certified
    • Stocking Flag : Y
    • Product Kit Identifier : N
    • Pep Code : ENVPEP2111016EN
    • Database Version : 2016-11
    • Pep Verification Date : 2021-11-01
    • Pcr Version : PCR-ed3-EN-2015 04 02
    • Psr Version : PSR-0005-ed2-EN-2016 03 29
    • Type Of Verification For The Pep : Independent internal review
    • Data Source : extrapolated product
    • Functional Unit Description : Protect during 20 years the installation against overloads and short-circuits in circuit with assigned voltage 120V and rated current 20A. This protection is ensured in accordance with the following parameters:& 10- Number of poles 1p& 10- Rated breaking capacity 10KA
    • Functional Unit Unit : unit
    • Energy Model Manufacturing A1 A3 2 : Energy model used: Mexico
    • Energy Model Installation A5 2 : Electricity mix; AC; 120V; US / Electricity mix; AC; 127V; MX
    • Energy Model Use B6 2 : Electricity mix; AC; 120V; US / Electricity mix; AC; 127V; MX
    • Energy Model End Of Life C1 C4 2 : Electricity mix; AC; 120V; US / Electricity mix; AC; 127V; MX
    • Global Commercial Status : Commercialised
    • Accessory Separate Part Type3 : rotatable fixing lug
  • Environment Attributes Main
    • Take Back : No, Nej
    • China ROHS Regulation : Product out of China RoHS scope , Pro-active China RoHS declaration (out of China RoHS legal scope)
    • EU ROHS Directive : Compliant , Compliant
    • ROHS Exemption Information : Yes
    • Halogene Performance : Halogen free product
    • Recycled Metal Content At Cr Level : 0 %
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Carbon Footprint : 19.7053604211
    • Environmental Disclosure : ENVPEP2111016EN
    • Halogen Content Performance : Halogen free product
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP2111016EN
    • Pep Verification Date : 2021-11-01
    • Pcr Version : PCR-ed3-EN-2015 04 02
    • Psr Version : PSR-0005-ed2-EN-2016 03 29
    • Type Of Verification For The Pep : Independent internal review
  • General Attributes
    • Product Or Component Type : miniature circuit-breaker
    • Range Of Product : QOU
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Depth : 2.95 in
