SQUARE D

Mini circuit breaker, QOU, 20A, 1 pole, 120/240 VAC, 22kA, field reversible lugs

MINIATURE CIRCUIT BREAKER 120/

SQDQOUR120VH QOUR120VH 785901853954
113.06 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QOU, 20A, 1 pole, 120/240 VAC, 22kA, field reversible lugs-1
  • Country of Origin: USA
  • Depth: 2.95 in
  • Height: 4.05 in
  • Warranty Length: 18 mth
  • Width: 0.75 in
QTY
  • Specifications
  • Environment
    • Product Certifications : UL Listed || IEC || CSA
  • Contractual warranty
    • Warranty : 18 months
  • Environmental data
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Halogen Content Performance : Halogen free product
    • Toxic Heavy Metal Free : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Reach Free Of Svhc : Yes
    • China Rohs Regulation : X
    • Circularity Profile : N/A
    • Take-Back : No
    • Eu Rohs Directive : Compliant
  • Complementary
    • Height : 4.05 in
    • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
    • Electrical Connection : slotted box lugs, line side || slotted box lugs, load side
    • Mounting Mode : unit mount
    • Line Rated Current : 20 A
    • Awg Gauge : AWG 14...AWG 2 aluminium/copper
    • Width : 0.75 in
    • Depth : 2.95 in
    • [Ue] Rated Operational Voltage : 120/240 V AC
  • Specifications
    • Country of Origin : United States
    • Width : 0.75 in
    • Height : 4.05 in
    • Range Of Product : QOU
    • Circuit Breaker Type : standard
    • Product Or Component Type : miniature circuit-breaker
    • Circuit Breaker Application : HACR rated
