Mini circuit breaker, QOU, 10A, 2 pole, 120/240 VAC, 10kA, ring terminal

Mini circuit breaker, QOU, 10A, 2 pole, 120/240 VAC, 10kA, ring terminal

SQDQOU2105283 QOU2105283 785901899372
115.21 / EACH
  • Certifications: CSA, IEC, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.95 in
  • Height: 4.05 in
  • Line Rated Current: 10 A
  • Mounting Type: Unit Mount
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 1.5 in
QO™ and QOU Miniature Circuit Breakers, QOU2105283, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Comes with factory installed ring tongue terminal.
  • Product Description
  • Specifications
QO™ and QOU Miniature Circuit Breakers, QOU2105283, is ideal for OEM applications. QOU miniature circuit breakers are used for overcurrent protection and switching on both AC and DC electrical systems. These Breakers These Breakers provide a means to manually open a circuit. Comes with factory installed ring tongue terminal.
  • Awg Gauge : AWG 14...AWG 2 aluminium/copper
  • Maximum Width : 1.5 in
  • Warranty : 18 months
  • Line Rated Current : 10 A
  • Circuit Breaker Type : standard
  • Maximum Depth : 2.95 in
  • Maximum Height : 4.05 in
  • Range Of Product : QOU
  • Poles Description : 2P
  • Electrical Connection : ring tongue, line side || ring tongue, load side
  • Tightening Torque : 45-45 lbf.in (AWG 14...AWG 2)
  • Product Or Component Type : miniature circuit-breaker
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC || 48 V DC
  • Product Certifications : UL Listed || IEC || CSA
  • Mounting Mode : unit mount
  • Short-Circuit Current : 10 kA || 5 kA
  • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 120 V AC || 5 kA 48 V DC
