Mini circuit breaker, QO, 80A, 2 pole, 120/240 VAC, 10 kA, bolt on mount, AC shunt trip

Mini circuit breaker, QO, 80A, 2 pole, 120/240 VAC, 10 kA, bolt on mount, AC shunt trip

SQDQOB2801021 QOB2801021 785901157458
400.62 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3.5 in
  • Line Rated Current: 80 A
  • Mounting Type: Bolt-On
  • Short Circuit Current: 10 kA
  • Warranty Length: 18 mth
  • Width: 2.25 in
QO(B) circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the “World’s Finest” Industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
  • Specifications
  • Circuit Breaker Application : HACR rated
  • Mounting Mode : bolt-on
  • Product Certifications : UL Listed || CSA
  • Maximum Depth : 2.91 in
  • Number Of Spaces Required : 3
  • Product Or Component Type : miniature circuit-breaker
  • Maximum Width : 2.25 in
  • Warranty : 18 months
  • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC
  • Line Rated Current : 80 A
  • Poles Description : 2P
  • Range Of Product : QO
  • Short-Circuit Current : 10 kA
  • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz
  • Accessory / Separate Part Type : shunt trip 120/208/240 V AC
  • Maximum Height : 3.5 in
  • Electrical Connection : box lugs
  • Ambient Air Temperature For Operation : 40 °C
  • Circuit Breaker Type : standard
  • Awg Gauge : AWG 4...AWG 2/0 copper or aluminium
