Mini circuit breaker, QO, 70A, 2 pole, 120/240 VAC, 22 kA, plug in mount

Mini circuit breaker, QO, 70A, 2 pole, 120/240 VAC, 22 kA, plug in mount

SQDQO270VH QO270VH 785901054986
80.11 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3.12 in
  • Line Rated Current: 70 A
  • Mounting Type: Plug-In
  • Short Circuit Current: 22 kA
  • Warranty Length: 18 mth
  • Width: 1.5 in
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick-break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This two pole QO plug in miniature circuit breaker is rated as 70A, 120/240 V. This circuit breaker provides 22 kA breaking capacity. This circuit breaker is UL Listed as SWD (switching duty) rated. It is suitable for switching 120 Vac fluorescent lighting loads. A full line of factory installed accessories, such as shunt trips, auxiliary switches and alarm switches are available. The box lugs will accept one 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.12 inches, a width of 1.50 inches and a depth of 2.91 inches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Product Description
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick-break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This two pole QO plug in miniature circuit breaker is rated as 70A, 120/240 V. This circuit breaker provides 22 kA breaking capacity. This circuit breaker is UL Listed as SWD (switching duty) rated. It is suitable for switching 120 Vac fluorescent lighting loads. A full line of factory installed accessories, such as shunt trips, auxiliary switches and alarm switches are available. The box lugs will accept one 8 AWG to 2 AWG copper or aluminum wire. This circuit breaker has a height of 3.12 inches, a width of 1.50 inches and a depth of 2.91 inches. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Awg Gauge : AWG 8...AWG 2 copper or aluminium
  • Mounting Mode : plug-in
  • Range Of Product : QO
  • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
  • Product Or Component Type : miniature circuit-breaker
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC
  • Circuit Breaker Application : HACR rated
  • Short-Circuit Current : 22 kA
  • Ambient Air Temperature For Operation : 40 °C
  • Product Certifications : UL Listed || CSA
  • Maximum Height : 3.12 in
  • Maximum Depth : 2.91 in
  • Circuit Breaker Type : standard
  • Number Of Spaces Required : 2
  • Line Rated Current : 70 A
  • Electrical Connection : box lugs
  • Warranty : 18 months
  • Breaking Capacity : 22 kA 120/240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
  • Poles Description : 2P
  • Maximum Width : 1.5 in
