Mini circuit breaker, QO, 60A, 3 pole, 120/240 VAC, 10 kA, plug in mount, AC shunt trip

Mini circuit breaker, QO, 60A, 3 pole, 120/240 VAC, 10 kA, plug in mount, AC shunt trip

SQDQO3601021 QO3601021 785901494164
216.91 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3.12 in
  • Line Rated Current: 60 A
  • Mounting Type: Plug-In
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 3 in
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QO miniature breaker is rated as 60 A, 120/240 V, and 3 pole. This unit provides 10 kA breaking capacity and plug in mounting. A full line of factory installed accessories is also available such auxiliary switches, alarm switches, and shunt trips. This unit has a factory installed shunt trip. QO breakers use a compact 3/4 inch width design for small system footprint. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
  • Product Description
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip-free toggle mechanism with quick-make, quick break action and positive handle indication They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This QO miniature breaker is rated as 60 A, 120/240 V, and 3 pole. This unit provides 10 kA breaking capacity and plug in mounting. A full line of factory installed accessories is also available such auxiliary switches, alarm switches, and shunt trips. This unit has a factory installed shunt trip. QO breakers use a compact 3/4 inch width design for small system footprint. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
  • Poles Description : 3P
  • Maximum Depth : 2.91 in
  • Ambient Air Temperature For Operation : 40 °C
  • Mounting Mode : plug-in
  • Electrical Connection : box lugs
  • [Ue] Rated Operational Voltage : 120/240 V AC || 240 V AC || 120 V AC || 48 V DC
  • Product Certifications : UL Listed || CSA
  • Awg Gauge : AWG 8...AWG 2 copper or aluminium
  • Maximum Width : 3 in
  • Product Or Component Type : miniature circuit-breaker
  • Line Rated Current : 60 A
  • Short-Circuit Current : 10 kA || 5 kA
  • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
  • Accessory / Separate Part Type : shunt trip 120/208/240 V AC
  • Circuit Breaker Application : HACR rated
  • Maximum Height : 3.12 in
  • Range Of Product : QO
  • Number Of Spaces Required : 4
  • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz || 10 kA 240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
  • Circuit Breaker Type : standard
  • Warranty : 18 months
