Mini circuit breaker, QO, 60A, 1 pole, 120/240 VAC, 22 kA, bolt on mount

Mini circuit breaker, QO, 60A, 1 pole, 120/240 VAC, 22 kA, bolt on mount

SQDQOB160VH QOB160VH 785901736257
80.31 / EA
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3.12 in
  • Line Rated Current: 60 A
  • Mounting Type: Bolt-On
  • Short Circuit Current: 22 kA
  • Warranty Length: 18 mth
  • Width: 0.75 in
  • Specifications
  • Maximum Width : 0.75 in
  • Poles Description : 1P
  • Mounting Mode : bolt-on
  • Tightening Torque : 4.6-4.6 N.m
  • Maximum Depth : 2.91 in
  • Line Rated Current : 60 A
  • Circuit Breaker Type : standard
  • Ambient Air Temperature For Operation : 40 °C
  • Short-Circuit Current : 22 kA
  • Awg Gauge : AWG 8...AWG 2 copper or aluminium
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC
  • Product Certifications : UL Listed || CSA
  • Warranty : 18 months
  • Range Of Product : QO
  • Electrical Connection : box lugs
  • Maximum Height : 3.12 in
  • Number Of Spaces Required : 1
  • Product Or Component Type : miniature circuit-breaker
  • Circuit Breaker Application : HACR rated
  • Breaking Capacity : 22 kA 120/240 V AC 50/60 Hz || 22 kA 120 V AC 50/60 Hz
