Mini circuit breaker, QO, 50A, 3 pole, 120/240 VAC, 10 kA, switch neutral, plug in mount, AC shunt trip

Mini circuit breaker, QO, 50A, 3 pole, 120/240 VAC, 10 kA, switch neutral, plug in mount, AC shunt trip

SQDQO350SWN1021 QO350SWN1021 785901088400
303.54 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Switch Neutral
  • Depth: 2.91 in
  • Height: 3.12 in
  • Line Rated Current: 50 A
  • Mounting Type: Plug-In
  • Short Circuit Current: 10 kA
  • Warranty Length: 18 mth
  • Width: 3 in
QO(B) circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the “World’s Finest” Industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
  • Specifications
  • Tightening Torque : 4.6-4.6 N.m
  • Electrical Connection : box lugs
  • Maximum Depth : 2.91 in
  • Product Certifications : UL Listed || CSA
  • Line Rated Current : 50 A
  • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz
  • Ambient Air Temperature For Operation : 40 °C
  • Maximum Height : 3.12 in
  • Range Of Product : QO
  • Circuit Breaker Application : not rated
  • Number Of Spaces Required : 4
  • Maximum Width : 3 in
  • Warranty : 18 months
  • Awg Gauge : AWG 8...AWG 2 copper or aluminium
  • Circuit Breaker Type : switch neutral
  • Accessory / Separate Part Type : shunt trip 120/208/240 V AC
  • Short-Circuit Current : 10 kA
  • Mounting Mode : plug-in
  • Poles Description : 3P
  • Product Or Component Type : miniature circuit-breaker
  • [Ue] Rated Operational Voltage : 120/240 V AC
