Mini circuit breaker, QO, 45A, 1 pole, 120/240 VAC, 10 kA, plug in mount

Mini circuit breaker, QO, 45A, 1 pole, 120/240 VAC, 10 kA, plug in mount

SQDQO145 QO145 785901012009
16.22 / EACH
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Standard
  • Depth: 2.91 in
  • Height: 3.12 in
  • Line Rated Current: 45 A
  • Mounting Type: Plug-In
  • Short Circuit Current: 10 kA, 5 kA
  • Warranty Length: 18 mth
  • Width: 0.75 in
QO(B) circuit breakers come in plug-on or bolt-on options and a complete range of amperages and interrupting ranges to fit into various QO distribution panels. QO is the “World’s Finest” Industry leading offer since 1955, with features engineered for faster installation, reliability and quality.
  • Specifications
  • Maximum Depth : 2.91 in
  • Number Of Spaces Required : 1
  • Poles Description : 1P
  • Mounting Mode : plug-in
  • Product Or Component Type : miniature circuit-breaker
  • Circuit Breaker Application : HACR rated
  • Range Of Product : QO
  • Maximum Width : 0.75 in
  • Short-Circuit Current : 10 kA || 5 kA
  • [Ue] Rated Operational Voltage : 120/240 V AC || 120 V AC || 48 V DC
  • Ambient Air Temperature For Operation : 40 °C
  • Awg Gauge : AWG 8...AWG 2 copper or aluminium
  • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz || 10 kA 120 V AC 50/60 Hz || 5 kA 48 V DC
  • Line Rated Current : 45 A
  • Electrical Connection : box lugs
  • Product Certifications : UL Listed || CSA
  • Circuit Breaker Type : standard
  • Maximum Height : 3.12 in
  • Tightening Torque : 5-5 N.m 10-25 mm² (AWG 8...AWG 2)
  • Warranty : 18 months
