Mini circuit breaker, QO, 30A, 3 pole, 208Y/120VAC, 10kA, 6mA grd fault A, pigtail, bolt on mount

MINIATURE CIRCUIT BREAKER 208Y

SQDQOB330GFI QOB330GFI 785901989226
791.36 / EACH
http://schema.org/OutOfStock
Mini circuit breaker, QO, 30A, 3 pole, 208Y/120VAC, 10kA, 6mA grd fault A, pigtail, bolt on mount
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Ground Fault Protecting Class A 6 MA
  • Depth: 74 mm
  • Height: 105 mm
  • Line Rated Current: 30 A
  • Mounting Type: Bolt-On
  • Net Weight: 0.600 kg
  • Warranty Length: 18 mth
  • Width: 57 mm
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 208Y/120VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a 6mA ground fault A with pigtail. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
QTY
  • Product Description
  • Specifications
QO and QOB one, two, and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on AC systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 208Y/120VAC. This unit provides 10kA breaking capacity and is bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a 6mA ground fault A with pigtail. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Environment
    • Product Certifications : UL Listed || CSA
    • Ambient Air Temperature For Operation : 40 °C
  • Contractual warranty
    • Warranty : 18 months
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Eu Rohs Directive : Compliant with Exemptions
  • Complementary
    • Height : 105 mm
    • Tightening Torque : 4-4 N.m || 4.6-4.6 N.m 4-20 mm² (AWG 12...AWG 4)
    • Number Of Spaces Required : 3
    • Net Weight : 0.600 kg
    • Breaking Capacity : 10 kA 208Y/120 V AC 50/60 Hz
    • Awg Gauge : AWG 12...AWG 4 aluminium || AWG 14...AWG 6 copper
    • Width : 57 mm
    • Depth : 74 mm
  • Specifications
    • Circuit Breaker Type : ground fault protecting class A 6 mA
    • Range Of Product : QO
    • Product Or Component Type : miniature circuit-breaker
    • Circuit Breaker Application : not rated
    • Mounting Mode : bolt-on
    • Poles Description : 3P
    • Electrical Connection : box lugs
    • Line Rated Current : 30 A
    • [Ue] Rated Operational Voltage : 208Y/120 V AC
