Mini circuit breaker, QO, 30A, 3 pole, 120/240VAC, 10kA, switch neutral, bolt on mount

MINIATURE CIRCUIT BREAKER 240V

SQDQOB330SWN QOB330SWN 785901368328
162.72 / EA
http://schema.org/OutOfStock
Mayer-Mini circuit breaker, QO, 30A, 3 pole, 120/240VAC, 10kA, switch neutral, bolt on mount-1
  • Certifications: CSA, UL Listed
  • Circuit Breaker Type: Switch Neutral
  • Depth: 74 mm
  • Height: 76 mm
  • Line Rated Current: 30 A
  • Mounting Type: Bolt-On
  • Net Weight: 0.386 kg
  • Warranty Length: 18 mth
  • Width: 57 mm
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a switch neutral. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
QTY
  • Product Description
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. This 3 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and bolt on mounting. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This product includes a switch neutral. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555
  • Specifications
    • Circuit Breaker Application : not rated
    • Mounting Mode : bolt-on
    • Circuit Breaker Type : switch neutral
    • Range Of Product : QO
    • Poles Description : 3P
    • Electrical Connection : pressure plate
    • Line Rated Current : 30 A
    • Product Or Component Type : miniature circuit-breaker
    • [Ue] Rated Operational Voltage : 120/240 V AC
  • Contractual warranty
    • Warranty : 18 months
  • Complementary
    • Height : 76 mm
    • Breaking Capacity : 10 kA 120/240 V AC 50/60 Hz
    • Tightening Torque : 4.6-4.6 N.m
    • Number Of Spaces Required : 3
    • Awg Gauge : AWG 14...AWG 8 copper or aluminium
    • Width : 57 mm
    • Depth : 74 mm
    • Net Weight : 0.386 kg
  • Offer Sustainability
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Sustainable Offer Status : Green Premium product
    • Toxic Heavy Metal Free : Yes
    • Eu Rohs Directive : Compliant
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Halogen Content Performance : Halogen free product
  • Environment
    • Product Certifications : UL Listed || CSA
    • Ambient Air Temperature For Operation : 40 °C
