SQUARE D

Mini circuit breaker, QO, 30A, 2 pole, 120/240VAC, 10kA, bolt on, Powerlink

MINIATURE CIRCUIT BREAKER 120/

SQDQOB230PL QOB230PL 785901095613
845.23 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QO, 30A, 2 pole, 120/240VAC, 10kA, bolt on, Powerlink-1
  • Country of Origin: USA
  • Depth: 74 mm
  • Height: 116 mm
  • Net Weight: 0.390 kg
  • Warranty Length: 18 mth
  • Weight: 0.390 kg
  • Width: 38 mm
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 2 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and bolt on mounting. This product has a Powerlink feature. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
QTY
  • Product Description
  • Features
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 2 pole QO circuit breaker is rated at 30A at 120/240VAC. This unit provides 10kA breaking capacity and bolt on mounting. This product has a Powerlink feature. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Environment
    • Product Certifications : UL Listed || CSA
    • Ambient Air Temperature For Operation : 40 °C
  • Contractual warranty
    • Warranty : 18 months
  • Environmental data
    • Packaging Made With Recycled Cardboard : No
    • Environmental Disclosure : ENVPEP1304033
    • Packaging Without Single Use Plastic : Yes
    • Scip Number : af42fb01-813d-40c0-ae28-b8b3299dbc99
    • California Proposition 65 : WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
    • China Rohs Regulation : X
    • Take-Back : No
  • Complementary
    • Height : 116 mm
    • Tightening Torque : 4-4 N.m
    • Provided Equipment : 18 in lead
    • Number Of Spaces Required : 2
    • Net Weight : 0.390 kg
    • Breaking Capacity : 10 kA 120/240 V AC || 10 kA 240 V AC || 10 kA 120 V AC
    • Awg Gauge : AWG 12...AWG 2 aluminium || AWG 14...AWG 2 copper
    • Width : 38 mm
    • Depth : 74 mm
  • Specifications
    • Country of Origin : United States
    • Width : 38 mm
    • Height : 116 mm
    • Weight : 0.390 kg
    • Circuit Breaker Type : standard
    • Range Of Product : QO
    • Product Or Component Type : miniature circuit-breaker
    • Circuit Breaker Application : HACR rated
    • Mounting Mode : bolt-on
    • Poles Description : 2P
    • Electrical Connection : box lugs
    • Line Rated Current : 30 A
    • [Ue] Rated Operational Voltage : 120/240 V AC || 240 V AC || 120 V AC
