SQUARE D

Mini circuit breaker, QO, 20A, 1 pole, 120VAC, 22kA, bolt on, dual function, pigtail [TAA]

MINIATURE CIRCUIT BREAKER 120V

SQDQOB120VHDF QOB120VHDF 785901765622
608.41 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, QO, 20A, 1 pole, 120VAC, 22kA, bolt on, dual function, pigtail [TAA]-1
  • Country of Origin: USA
  • Depth: 74 mm
  • Height: 121 mm
  • Net Weight: 0.118 kg
  • Weight: 0.118 kg
  • Width: 19 mm
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 120VAC. This unit provides 22kA breaking capacity and bolt on mounting. This product includes a dual function feature with pigtail. This provides combination arc fault and ground fault protection. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
QTY
  • Product Description
  • Features
  • Specifications
QO and QOB one, two and three pole thermal magnetic circuit breakers provide overcurrent protection and switching on ac and dc systems. These circuit breakers have an over center, trip free toggle mechanism with quick make, quick break action and positive handle indication. They also have VisiTrip trip indication, which provides a visual indication that the circuit breaker has tripped and interrupted the circuit. A full line of features and factory installed accessories are also available such as shunt trips, auxiliary switches and alarm switches. This 1 pole QO circuit breaker is rated at 20A at 120VAC. This unit provides 22kA breaking capacity and bolt on mounting. This product includes a dual function feature with pigtail. This provides combination arc fault and ground fault protection. QO circuit breakers are UL Listed under UL File E84967 and are CSA Certified under CSA Master Contract 153555.
  • Prop 65
    • WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
  • Specifications
    • Country of Origin : United States
    • Width : 19 mm
    • Height : 121 mm
    • Weight : 0.118 kg
    • Connections - Terminals : pigtail neutral
    • Circuit Breaker Type : combination ARC-fault and ground fault
    • Range Of Product : QO
    • Product Or Component Type : miniature circuit-breaker
    • Circuit Breaker Application : HACR rated
    • Mounting Mode : bolt-on
    • Poles Description : 1P
    • Electrical Connection : pressure plate
    • Line Rated Current : 20 A
    • [Ue] Rated Operational Voltage : 120 V AC
  • Environmental data
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : Yes
    • California Proposition 65 : WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
    • Take-Back : No
  • Environment
    • Product Certifications : UL Listed || CSA
    • Ambient Air Temperature For Operation : 40 °C
  • Complementary
    • Height : 121 mm
    • Tightening Torque : 4.6-4.6 N.m
    • Number Of Spaces Required : 1
    • Net Weight : 0.118 kg
    • Breaking Capacity : 22 kA 120 V AC
    • Awg Gauge : AWG 14...AWG 8 copper or aluminium || AWG 14...AWG 10 copper
    • Width : 19 mm
    • Depth : 74 mm
