Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides

• Circuit Breaker Type
• ground fault protecting class B 30 mA
• Prop 65
• WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
• Carbon Footprint Of The Installation Phase A5
• 0.001111249
• 0 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4
• 0.1 kg CO2 eq.
• 0.1079287725
• Ue Rated Operational Voltage
• 120/240 V AC
• Carbon Footprint Of The Manufacturing Phase A1 To A3
• 3 kg CO2 eq.
• 2.889046808
• Persona Type Names
• End User
• Consumer
• Contractor
• Electrician
• Carbon Footprint Of The Use Phase B2 B3 B4 B6
• 39 kg CO2 eq.
• 39.066
• Persona Type Ids
• EU
• EUA
• LC
• SC
• Carbon Footprint Of The Distribution Phase A4
• 0.0678885713
• 0.1 kg CO2 eq.
• Tightening Torque
• 4.6-4.6 N.m 2.5-10 mm² (AWG 16...AWG 14)
• 4.6-4.6 N.m 4-20 mm² (AWG 12...AWG 4)
• Awg Gauge
• 1 x AWG 14...AWG 8 ( aluminium/copper )

• Conformance Attributes
• Product Certifications : UL Listed
• Complementary Attributes
• Line Rated Current : 30 A
• Important Information Attributes
• Local Data Status : Publishable
• Local Publishable Date : 2025-07-09
• Device Type : LV equipment - Low voltage circuit breaker
• Serviceability : No
• Traceability : No
• Field Service Division : PPIBS
• Average Life Duration : 15 year(s)
• Manufacturing Carbon Footprint : 2.889046808
• Distribution Carbon Footprint : 0.0678885713
• Installation Carbon Footprint : 0.001111249
• Use Carbon Footprint : 39.066
• End Of Life Carbon Footprint : 0.1079287725
• Legacy Weee Scope : In
• Weee Product Category : 5
• Scope Perimeter : Outside of Europe
• Eoli Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1406034
• Rohs Eur In Scope : Yes
• Rohs Eur Status : Compliant with Exemptions
• Rohs Eur Conformity Date : 2532
• Rohs Eur Full Compliance Status : Compliant with Exemptions
• China Rohs In Scope : No
• With Recycled Cardboard : No
• Without Single Use Plastic : Yes
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• Wd Status : 1 - GSC certified
• Tier Id : 1
• Tier : 1
• Function Option Id : STANDARD
• Function Option : Standard
• Market Segmentation Id : RESIDENTIAL
• Market Segmentation : Residential
• H And D Domain : Safety
• H And D Subrange : RESI
• H And D Enrichment Assignment : yes
• H And D Enrichment Function : EPD
• H And D Enrichment Class 3 : Earth leakage protection devices
• H And D Enrichment Class 4 : EPD
• Circuit Breaker Application : HACR rated
• Electrical Connection : screw clamp terminals
• Energy Efficiency Optimized : False
• Halogen Free Status : Halogen free product
• Mounting Mode : plug-in
• Number Of Spaces Required : 2
• Package Weight Lbs : 526.167 g
• Poles Description : 2P
• Product Availability : Stock - Normally stocked in distribution facility
• Product Or Component Type : miniature circuit-breaker
• Range Of Product : Homeline
• Returnability : Yes
• Short Circuit Current : 10 kA
• Sustainable Packaging : No
• Total Lifecycle Carbon Footprint : 42 kg CO2 eq.
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 42.1319754008
• General Attributes
• Product Or Component Type : miniature circuit-breaker
• Range Of Product : Homeline
• Environment Attributes
• Take Back : No
• Halogene Performance : Halogen free product
• China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
• Mercury Free : Yes
• Carbon Footprint : 42.1319754008
• Ambient Air Temperature For Operation : 40 °C
• Circularity Profile : ENVEOLI1406034
• Environmental Disclosure : ENVPEP1406034
• Eu Rohs Directive : Compliant with Exemptions
• Halogen Content Performance : Halogen free product
• Packaging Made With Recycled Cardboard : No
• Packaging Without Single Use Plastic : Yes
• Contractual Warranty Attributes
• Warranty Period : Lifetime
• Warranty : Lifetime
• Specifications
• Country of Origin : Mexico
• Compliance : TAA
