SQUARE D

Mini branch circuit breaker, Homeline, 175A, 2 pole, 120/240VAC, 10kA AIR, standard type, plug in, UL

MINIATURE CIRCUIT BREAKER 120/

SQDHOM2175BB HOM2175BB 785901264477
422.84 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini branch circuit breaker, Homeline, 175A, 2 pole, 120/240VAC, 10kA AIR, standard type, plug in, UL-1
  • Country of Origin: USA
  • Depth: 3.13 in
  • Height: 5.39 in
  • Short Circuit Current Rating: 10 kA
  • Warranty Length: Lifetime
  • Width: 3.98 in
Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 175 A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 300 kcmil copper or aluminum wire. This circuit breaker has a height of 5.39 inches, a width of 3.98 inch and depth of 3.13 inches. HOM Homeline miniature circuit breakers are UL Listed.
QTY
  • Product Description
  • Features
  • Specifications
Homeline miniature circuit breakers are engineered and designed for fast installation and superior circuit protection. Homeline circuit breakers are designed to plug into Homeline load centers to provide circuit protection. This circuit breaker provides standard circuit protection and is HACR rated. This 2 pole circuit breaker with plug in mounting is rated 175 A at 120/240 VAC. HOM breakers provide 10 kA breaking capacity. The electrical connections are box lugs that will accept 1 wires. The box lugs will accept a wire range of 4 AWG to 300 kcmil copper or aluminum wire. This circuit breaker has a height of 5.39 inches, a width of 3.98 inch and depth of 3.13 inches. HOM Homeline miniature circuit breakers are UL Listed.
  • Prop 65
    • "WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov"
  • Environment
    • Ambient Air Temperature For Operation : 40 °C
  • Contractual warranty
    • Warranty : Lifetime
  • Environmental data
    • Rohs Exemption Information : Yes
    • Packaging Made With Recycled Cardboard : No
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1308001
    • Packaging Without Single Use Plastic : No
    • California Proposition 65 : "WARNING: This product can expose you to chemicals including: Cadmium and cadmium compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov"
    • Circularity Profile : N/A
    • Take-Back : No
    • Eu Rohs Directive : Compliant with Exemptions
    • Carbon Footprint (Kg Co2 Eq, Total Life Cycle) : 28.1789198851
  • Complementary
    • Height : 5.39 in
    • Tightening Torque : 28.3-28.3 N.m 95-150 mm² (AWG 4/0...250 kcmil)
    • Width : 3.98 in
    • Depth : 3.13 in
  • Specifications
    • Country of Origin : United States
    • Width : 3.98 in
    • Height : 5.39 in
    • Product Certifications : UL Listed
    • Circuit Breaker Type : standard
    • Range Of Product : Homeline
    • Number Of Spaces Required : 4
    • Product Or Component Type : miniature circuit-breaker
    • Circuit Breaker Application : HACR rated
    • Mounting Mode : plug-in
    • Short-Circuit Current : 10 kA
    • Poles Description : 2P
    • Electrical Connection : box lugs
    • Line Rated Current : 175 A
    • [Ue] Rated Operational Voltage : 120/240 V AC
    • Awg Gauge : 1 x AWG 4...300 kcmil ( aluminium/copper )
