MP Meter Pak, meter center, four ringless sockets, lever bypass, 5th jaw, OH, UG, 600 A bus, 225 A, 240 VAC single phase 3W

MP Meter Pak, meter center, four ringless sockets, lever bypass, 5th jaw, OH, UG, 600 A bus, 225 A, 240 VAC single phase 3W

SQDMPL64225 MPL64225 785901336563
2795.00 / EACH
  • Country of Origin: Mexico
  • Depth: 244.35 mm, 9.62 in
  • Enclosure: 3R
  • Enclosure Material: Steel
  • Height: 1711.20 mm, 67.37 in
  • Number of Phases: 1
  • Warranty Length: 18 mth
  • Width: 35.37 in, 898.40 mm
MP Meter Pak meter centers offer a wide range of multimetering applications. MP meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations are available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPL meter center has four ringless meter sockets with lever bypass and a 5 jaw socket. This main lugs unit can be feed from an overhead or underground service. The aluminum main bus ampacity is 600 A. The maximum tenant main lugs amperage is 225 A with a 240 VAC 3 wire single phase maximum. This unit has a NEMA 3R surface mounting enclosure that is 67.37 inches tall, 35.37 inches wide and 9.62 inches deep. This MPL meter center with accept one 1/0 AWG to 600 kcmil or two 1/0 AWG to 250 kcmil copper or aluminum wire. This MPL meter center unit is UL Listed.
  • Product Description
  • Specifications
MP Meter Pak meter centers offer a wide range of multimetering applications. MP meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations are available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPL meter center has four ringless meter sockets with lever bypass and a 5 jaw socket. This main lugs unit can be feed from an overhead or underground service. The aluminum main bus ampacity is 600 A. The maximum tenant main lugs amperage is 225 A with a 240 VAC 3 wire single phase maximum. This unit has a NEMA 3R surface mounting enclosure that is 67.37 inches tall, 35.37 inches wide and 9.62 inches deep. This MPL meter center with accept one 1/0 AWG to 600 kcmil or two 1/0 AWG to 250 kcmil copper or aluminum wire. This MPL meter center unit is UL Listed.
  • Complementary
    • Enclosure Material : Steel
    • Main Rating : 400 A || 600 A
    • Wire Size : AWG 1/0...600 kcmil 1 aluminium || AWG 1/0...600 kcmil 1 copper
    • Bypass Type : Lever bypass
    • Mounting : Surface
    • Type : Meter-Pak
    • Phase : 1 phase
    • Wire Configuration : 3-wire
    • Depth : 9.62 in (244.35 mm)
    • Width : 35.37 in (898.40 mm)
    • Certifications : UL Listed
    • Height : 67.37 in (1711.20 mm)
    • Enclosure Rating : NEMA 3R
    • Maximum Voltage Rating : 240 V AC
    • Service Feed Location : OH || UG
    • Bus Rating : 600 A
    • Busbar Material : Aluminium: busbar
  • Contractual Warranty
    • Warranty : 18 months
  • Main
    • Main Type : Main Lugs
    • Socket Rating : 225 A
    • Socket Type : Ringless
    • Number Of Meter Sockets : 4
    • Product : Meter Center
    • Number Of Jaws : 5
  • Offer Sustainability
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Toxic Heavy Metal Free : Yes
    • REACh Free Of SVHC : Yes
    • Mercury Free : Yes
    • EU RoHs Directive : Compliant
  • Ordering And Shipping Details
    • Discount Schedule : DE4
    • Country Of Origin : MX
    • GTIN : 00785901336563
    • Returnability : Yes
    • Nbr. Of Units In Pkg. : 1
    • Category : 00021 - METER-PAK
