SQUARE D

MP Meter Pak, meter center, five ringless sockets, horn bypass, 5th jaw, 800 A bus, 200 A, 240 VAC single phase 3W

MTR MP DEVICE RINGLESS HORN 20

SQDMPH85200 MPH85200 785901410539
2047.40 / EACH
  • Certifications: UL
  • Enclosure Material: Steel
  • Material: Aluminum
  • Number of Phases: 1
MPH Meter Pak meter centers offer a wide range of multimetering applications. MPH meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPH meter center has a ringless socket with a horn bypass and a 5th jaw. The aluminum main bus ampacity is 800 A. This MPH meter pak meter center has 5 meter sockets. The maximum tenant main lugs amperage is 200 A with a 240 VAC single phase maximum. This MPH meter center with accept 3/0 AWG to two 500 kcmil copper or aluminum wire. Meter center is UL listed.
  • Product Description
  • Specifications
MPH Meter Pak meter centers offer a wide range of multimetering applications. MPH meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPH meter center has a ringless socket with a horn bypass and a 5th jaw. The aluminum main bus ampacity is 800 A. This MPH meter pak meter center has 5 meter sockets. The maximum tenant main lugs amperage is 200 A with a 240 VAC single phase maximum. This MPH meter center with accept 3/0 AWG to two 500 kcmil copper or aluminum wire. Meter center is UL listed.
  • [Ue] Rated Operational Voltage : 240 V AC
  • Material : aluminium busbar
  • Main Type : Main Lugs
  • Product Mounting : surface
  • Meter Socket Type : ringless
  • Phase : 1 phase
  • Meter Socket Rated Current : 200 A
  • Number Of Meter Sockets : 5
  • Nema Degree Of Protection : NEMA 3R
  • Main Rated Current : 600 A || 750 A
  • Service Feed Location : OH || UG
  • Product Certifications : UL Listed
  • Wiring Configuration : 3-wire
  • Awg Gauge : AWG 3/0...500 kcmil 2 aluminium || AWG 3/0...500 kcmil 2 copper
  • Bypass Type : horn bypass
  • Bus Rated Current : 800 A
  • Number Of Jaws : 5
  • Enclosure Material : steel
  • Range Of Product : Meter-Pak
  • Product Or Component Type : Meter Center
