MP Meter Pak, meter center, five ringless sockets, horn bypass, 5th jaw, 500 A bus, 125 A, 240 VAC single phase 3W

MP Meter Pak, meter center, five ringless sockets, horn bypass, 5th jaw, 500 A bus, 125 A, 240 VAC single phase 3W

SQDMPH55125 MPH55125 785901208136
1781.00 / EACH
  • Country of Origin: Mexico
  • Enclosure: 3R
  • Enclosure Material: Steel
  • Number of Phases: 1
  • Warranty Length: 18 mth
MPH Meter Pak meter centers offer a wide range of multimetering applications. MPH meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPH meter center has a ringless socket with a horn bypass and a 5th jaw. The aluminum main bus ampacity is 500 A. This MPH meter pak meter center has 5 meter sockets. The maximum tenant main lugs amperage is 125 A with a 240 VAC single phase maximum. This MPH meter center with accept 1/0 AWG to 600 kcmil copper or aluminum wire. Meter center is UL listed.
  • Product Description
  • Specifications
MPH Meter Pak meter centers offer a wide range of multimetering applications. MPH meter centers have UL Listed indoor rainproof NEMA Type 3R construction which meets EUSERC standards. The 9 inch meter center spacing allows for more sockets per device. This creates lighter and more compact branch enclosures. Four meter socket configurations available with options such as ring or ringless, 4 and 5 jaw, horn or lever, and jaw release. This MPH meter center has a ringless socket with a horn bypass and a 5th jaw. The aluminum main bus ampacity is 500 A. This MPH meter pak meter center has 5 meter sockets. The maximum tenant main lugs amperage is 125 A with a 240 VAC single phase maximum. This MPH meter center with accept 1/0 AWG to 600 kcmil copper or aluminum wire. Meter center is UL listed.
  • Main
    • Number Of Jaws : 5
    • Socket Rating : 125 A
    • Number Of Meter Sockets : 5
    • Product : Meter Center
    • Socket Type : Ringless
    • Main Type : Main Lugs
  • Contractual Warranty
    • Warranty : 18 months
  • Complementary
    • Bypass Type : Horn bypass
    • Maximum Voltage Rating : 240 V AC
    • Mounting : Surface
    • Service Feed Location : UG || OH
    • Wire Size : AWG 1/0...600 kcmil 1 aluminium || AWG 1/0...600 kcmil 1 copper
    • Busbar Material : Aluminium: busbar
    • Phase : 1 phase
    • Certifications : UL Listed
    • Enclosure Rating : NEMA 3R
    • Main Rating : 500 A || 400 A
    • Bus Rating : 500 A
    • Wire Configuration : 3-wire
    • Enclosure Material : Steel
    • Type : Meter-Pak
  • Offer Sustainability
    • REACh Free Of SVHC : Yes
    • Mercury Free : Yes
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Toxic Heavy Metal Free : Yes
    • EU RoHs Directive : Compliant
  • Ordering And Shipping Details
    • Category : 00021 - METER-PAK
    • Returnability : Yes
    • Discount Schedule : DE4
    • Country Of Origin : MX
    • GTIN : 00785901208136
    • Nbr. Of Units In Pkg. : 1
