MOLDED CASE CIRCUIT BREAKER 600V 250A

MOLDED CASE CIRCUIT BREAKER 600V 250A

SQDJDL36250AASA JDL36250AASA 785901946830
3987.78 / EACH
  • Country of Origin: USA
  • Line Rated Current: 250 A
  • Mounting Type: Unit Mount
  • Number of Poles: 3
  • Package Weight: 5 lb
  • Trip Point: 2500 A
  • Voltage: 250 V, 600 V
  • Warranty Length: 18 mth
The PowerPact H, J, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. L-frame circuit breakers are available with Micrologic electronic trip units only.
  • Product Description
  • Features
  • Specifications
The PowerPact H, J, and L-frame circuit breakers are designed to protect electrical systems from damage caused by overloads and short circuits. H and J-frame circuit breakers are available with either thermal-magnetic or Micrologic electronic trip units. L-frame circuit breakers are available with Micrologic electronic trip units only.
  • Flexible and simple offer, with proven performance
  • Direct access to energy metering and energy efficiency thanks to the Micrologic control units
  • Worldwide availability with unique global part numbers
  • Commercial Buildings
  • Industrial Buildings
  • Industrial Markets
  • Healthcare Facilities
  • Construction
  • Educational Campuses
  • Oil & Gas
  • Data Centers
  • OEM Commercial
  • Marine
  • Complementary
    • Number Of Poles : 3
    • Continuous Current Rating : 80 %
    • Poles Description : 3P
    • Width : 4.12 in
    • AWG Gauge : AWG 3/0...350 kcmil aluminium/copper
    • Magnetic Hold Current : 1250 A
    • Mounting Mode : Unit mount
    • Line Rated Current : 250 A
    • Height : 7.52 in
    • Electrical Connection : Lugs load || Lugs line
    • Breaking Capacity : 25 kA 240 V AC || 18 kA 480 V AC || 14 kA 600 V AC || 20 kA 250 V DC
    • Magnetic Tripping Current : 2500 A
    • System Voltage : 250 V DC || 600 V AC
    • Depth : 5 in
  • Contractual Warranty
    • Warranty Period : 18 months
  • Main
    • Accessory / Separate Part Type : Shunt trip 120 V AC || Auxiliary switch 1 NO + 1 NC
    • Trip Unit Technology : Thermal-magnetic
    • Range Of Product : PowerPact J
    • Product Or Component Type : Circuit breaker
    • Breaking Capacity Code : D
  • Offer Sustainability
    • Product End Of Life Instructions : Need no specific recycling operations
    • Product Environmental Profile : Available
    • RoHS (Date Code: YYWW) : Compliant  - since  0832  -  Schneider Electric declaration of conformity
    • Sustainable Offer Status : Green Premium product
  • Environment
    • Product Certifications : CCC || CE || CSA || IEC || UL listed
    • Ambient Air Temperature For Operation : 104 °F (40 °C)
  • Ordering and Shipping Details
    • Category : 01110 - HD,JD UNIT MT BREAKER/SWITCH
    • Country Of Origin : US
    • Returnability : N
    • Discount Schedule : DE2
    • Number Of Units In Package : 1
    • GTIN : 00785901946830
    • Package Weight(Lbs) : 5
