Industrial measurement and relay, Harmony relay, plug-in liquid level control relay RM84, 8 pins, 24V AC, 1 C/O

LIQUID LEVEL RELAY 250V 8A RM8

SQDRM84870301 RM84870301 3389110282382
59.40 / EA
http://schema.org/OutOfStock
Mayer-DDS-Industrial measurement and relay, Harmony relay, plug-in liquid level control relay RM84, 8 pins, 24V AC, 1 C/O-1
  • Country of Origin: France
  • Warranty Length: 18 mth
QTY
  • Features
  • Specifications
  • Contacts Type And Composition
    • 1 C/O relay output, AgCdO
    • 1 C/O
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Response Time
    • 300 ms high level
    • 500 ms low level
  • Maximum Output Current
    • 8 mA AC AC-1 resistive
  • Isolation Voltage
    • 2500 V AC contacts and electrodes from the supply
  • Maximum Electrode Current
    • 1 mA 50/60 Hz
  • Market Segmentation
    • Commercial
    • Industrial
  • Persona Type Names
    • Charge Point Operator
    • End User
    • Contractor
    • Original Equipment Manufacturer
    • OEM - Control Panelbuilder
    • Panel Builder
    • Electrician
    • System Integrator
    • IT Channel Partner
  • Persona Type Ids
    • BM9
    • EU
    • LC
    • OM
    • OM8
    • PB
    • SC
    • SI
    • VR
  • Maximum Electrode Voltage
    • 24 V AC 50/60 Hz
  • Market Segmentation Id
    • COMMERCIAL
    • INDUSTRIAL
  • Complementary Attributes
    • Maximum Cable Capacity : 0 mF
    • Maximum Power Consumption In VA : 3 VA
  • Important Information Attributes
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-07-09
    • Legacy WEEE Scope : Out
    • WEEE Product Category : 5
    • Scope Perimeter : At least in Europe
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Conformity Date : 1840
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : Yes
    • China ROHS Label : 5
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 1 - GSC certified
    • Tier Id : 1
    • Tier : 1
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Package Weight Lbs : 171.900 g
    • Pin Number : 8
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : industrial measurement and control relays
    • Range Of Product : Harmony Relay
    • Relay Monitored Parameters : detection by resistive probes
    • Relay Name : RM84870
    • Returnability : Yes
    • Sensitivity Scale : 5...100 kOhm
    • Sustainable Packaging : Yes
    • Nbr Of Units In Pkg : 1
    • Warranty In Months : 18
  • General Attributes
    • Product Or Component Type : industrial measurement and control relays
    • Range Of Product : Harmony Relay
  • Environment Attributes
    • China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=648426&lang=en-us
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : X
    • Mercury Free : Yes
    • Ambient Air Temperature For Operation : -20-60 °C
    • EU ROHS Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Country of Origin : France
