Meter socket, ringed, 1 phase, 3 wire, 7 jaws, solid top, test block bypass, no jaw release

MULTI-METERING BUCKET 3PHASE

SQDCM732E CM732E 785901744337
2199.23 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Meter socket, ringed, 1 phase, 3 wire, 7 jaws, solid top, test block bypass, no jaw release-1
  • Number of Jaws: 7 Without Jaw Release, 7 Without Jaw Release
  • Warranty Length: 18 mth
Square D individual meter sockets have provisions to feed a downstream main lug load center, main breaker load center, or an individually enclosed service disconnect. Units can have a combination of releases, horn, or no bypasses to handle any meter socket situation. Units supplied with hub opening in top end wall require the use of a bolt-on hub or closing plate. With 200 A, 600 V, 1 phase, 7 jaws, ringless socket your product can provide 10 kA RMS short circuit rating. These units are supplied with a bonded neutral to the NEMA 3R enclosure. Meter sockets are UL Listed. This meter has test block bypass allowing for continued service during meter maintenance or replacement.
QTY
  • Product Description
  • Features
  • Specifications
Square D individual meter sockets have provisions to feed a downstream main lug load center, main breaker load center, or an individually enclosed service disconnect. Units can have a combination of releases, horn, or no bypasses to handle any meter socket situation. Units supplied with hub opening in top end wall require the use of a bolt-on hub or closing plate. With 200 A, 600 V, 1 phase, 7 jaws, ringless socket your product can provide 10 kA RMS short circuit rating. These units are supplied with a bonded neutral to the NEMA 3R enclosure. Meter sockets are UL Listed. This meter has test block bypass allowing for continued service during meter maintenance or replacement.
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Complementary Attributes
    • UE Rated Operational Voltage : 208Y/120 V AC, 208Y/120 V AC, 240/120 V delta AC, 240/120 V delta AC, 480Y/277 V AC, 480Y/277 V AC
  • Important Information Attributes
    • AWG Gauge : AWG 6...350 kcmil aluminium/copper)line side, AWG 6...350 kcmil aluminium/copper)line side, AWG 6...350 kcmil aluminium/copper)line side, AWG 6...350 kcmil aluminium/copper)service ground, AWG 6...350 kcmil aluminium/copper)service ground, AWG 6...350 kcmil aluminium/copper)service ground
    • Number Of Jaws : 7 without jaw release, 7 without jaw release
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-11-18
    • Legacy WEEE Scope : In
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : No need of specific recycling operations
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : Yes
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status : Compliant with Exemptions
    • ROHS EUR Full Compliance Status Id : COMPLIANT_WITH_EXEMPTIONS
    • China ROHS In Scope : No
    • Green Premium Status For Reporting : Green Premium product
    • With Recycled Cardboard : No
    • Without Single Use Plastic : No
    • Product Contributes To Saved And Avoided Emissions : No
    • Return Indicator : Y
    • WD Status : 5 - INITIALIZED WITH DataSCAN OK (Migration)
    • Persona Type Ids : EU
    • Persona Type Names : End User
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : RESIDENTIAL
    • Market Segmentation : Residential
    • H And D Domain : Safety
    • H And D Subrange : RESI
    • H And D Enrichment Assignment : yes
    • H And D Enrichment Function : ACCESSORIES
    • H And D Enrichment Class 3 : Enclosures
    • H And D Enrichment Class 4 : Enclosure accessory
    • Electrical Connection : plug-in
    • Energy Efficiency Optimized : False
    • Hub Type : solid top
    • Meter Socket Type : ringed
    • Package Weight Lbs : 6.904 kg
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : Meter Socket
    • Returnability : Yes
    • Sustainable Packaging : No
    • Wiring Configuration : 4-wire
    • Relationship Type : Compatible relationship
    • Pep Code : ENVPEP2509019EN
    • Product Kit Identifier : N
  • Environment Attributes Main
    • EU ROHS Directive : Compliant By Exemption​, Compliant with Exemptions
    • ROHS Exemption Information : Yes
    • Take Back : No
    • Recycled Metal Content At Cr Level : 0 %
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2509019EN
    • Packaging Made With Recycled Cardboard : No
    • Packaging Without Single Use Plastic : No
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP2509019EN
  • General Attributes
    • Product Or Component Type : Meter Socket
  • Output Attributes
    • Bypass Type : test block bypass
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
