SQUARE D

Head for key selector switch, Harmony XB5, flush mounted 8D1 2 pos stay put

HEAD FOR KEY SELECTOR SWITCH,

SQDZB5FG4D 3606481339409
79.03 / EA
http://schema.org/OutOfStock
Mayer-DDS-Head for key selector switch, Harmony XB5, flush mounted 8D1 2 pos stay put-1
  • Bezel Material: Plastic
  • Certifications: BV, CSA, DNV, GL, LROS (Lloyds Register Of Shipping), UL Listed
  • IsSustainable: No
  • Net Weight: 0.069 kg
  • Standard: CSA C22.2 No 14, EN/IEC 60947-1, EN/IEC 60947-5-1, EN/IEC 60947-5-4, JIS C8201-1, JIS C8201-5-1, UL 508
  • Storage Temperature: -40-70 °C
This 30mm key selector switch head, dom 8d1 and Ronis 3131a provides an ergonomic interface for controlling your machine. It is easily installed/replaced on compatible selector switch units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration, impact resistant, high pressure washer resistant and dust resistant thanks to its IP69, IP67, IP66 protection, making it ideal for operation in harsh environments.
QTY
  • Product Description
  • Specifications
This 30mm key selector switch head, dom 8d1 and Ronis 3131a provides an ergonomic interface for controlling your machine. It is easily installed/replaced on compatible selector switch units and contact blocks via snap-fit assembly. It is clearly distinguishable visually at a distance thanks to its clear color. It is vibration, impact resistant, high pressure washer resistant and dust resistant thanks to its IP69, IP67, IP66 protection, making it ideal for operation in harsh environments.
  • Environment
    • Ip Degree Of Protection : IP66 IEC 60529 || IP67 || IP69 || IP69K
    • Overvoltage Category : class II IEC 60536
    • Ambient Air Temperature For Operation : -40-70 °C
    • Nema Degree Of Protection : NEMA 13 || NEMA 4X
    • Ambient Air Temperature For Storage : -40-70 °C
    • Ik Degree Of Protection : IK03 IEC 50102
    • Standards : UL 508 || EN/IEC 60947-5-1 || EN/IEC 60947-1 || JIS C8201-5-1 || CSA C22.2 No 14 || EN/IEC 60947-5-4 || JIS C8201-1
    • Product Certifications : LROS (Lloyds register of shipping) || UL Listed || DNV || BV || CSA || GL
    • Shock Resistance : 30 gn 18 ms) half sine wave acceleration IEC 60068-2-27 || 50 gn 11 ms) half sine wave acceleration IEC 60068-2-27
    • Protective Treatment : TH
    • Resistance To High Pressure Washer : 7000000 Pa 55 °C 0.1 m
    • Vibration Resistance : 5 gn 2-500 Hz)IEC 60068-2-6
  • Specifications
    • Bezel Material : dark grey plastic
    • Shape Of Signaling Unit Head : round
    • Type Of Keylock : key 3131A || Dom 8D1
    • Type Of Operator : stay put
    • Head Type : built-in-flush
    • Product Or Component Type : head for key selector switch
    • Mounting Diameter : 30.5 mm
    • Sale Per Indivisible Quantity : 1
    • Operator Profile : black key switch
    • Device Short Name : ZB5
    • Range Of Product : Harmony XB5
    • Operator Position Information : 2 positions 90°
    • Key Withdrawal Position : in any position
  • Offer Sustainability
    • Circularity Profile : ENVEOLI1710010EN
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1710010EN
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Sustainable Offer Status : Green Premium product
    • Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • China Rohs Regulation : X
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Rohs Exemption Information : Yes
  • Complementary
    • Net Weight : 0.069 kg
    • Cad Overall Width : 37 mm
    • Electrical Composition Code : C4 6 single and double front mounting || C5 5 single front mounting || C6 5 single and double front mounting || C7 4 single front mounting || C8 4 single and double front mounting || C11 3 single front mounting || C3 6 single front mounting || SF1 3 single front mounting || C15 1 single front mounting
    • Cad Overall Depth : 72 mm
    • Mechanical Durability : 1000000 cycles
    • Cad Overall Height : 37 mm
