SQUARE D

Mini circuit breaker, E-Frame, 50A, 3 pole, 600Y/347VAC, 25kA max, bolt on [TAA]

MINIATURE CIRCUIT BREAKER 600V

SQDEDB36050 EDB36050 785901234807
713.70 / EACH
http://schema.org/OutOfStock
Mayer-DDS-Mini circuit breaker, E-Frame, 50A, 3 pole, 600Y/347VAC, 25kA max, bolt on [TAA]-2
  • Module Type: E-Frame
  • Number of Poles: 3
  • Number of Spaces: 3
  • Warranty Length: 18 mth
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer super
QTY
  • Product Description
  • Features
  • Specifications
E-Frame Breaker are Lighting Panelboard Circuit breakers that are proven effective and reliable which provide a wide variety or robust features that are use specifically in Square D NF Panelboards. This range of breaker is ideally designed to offer super
  • Carbon Footprint Of The Installation Phase A5
    • 0.0430429622
    • 0 kg CO2 eq.
  • Carbon Footprint Of The End Of Life Phase C1 To C4
    • 0.2 kg CO2 eq.
    • 0.2399876757
  • Electrical Connection
    • lugs aluminium
  • Carbon Footprint Of The Manufacturing Phase A1 To A3
    • 8 kg CO2 eq.
    • 7.9913286486
  • Accessories
    • N150MH
    • N400M
    • HPAFD
    • EDPAF
    • AL100FD
  • Persona Type Names
    • End User
    • Contractor
    • Original Equipment Manufacturer
  • Carbon Footprint Of The Use Phase B2 B3 B4 B6
    • 51 kg CO2 eq.
    • 50.548
  • Persona Type Ids
    • EU
    • LC
    • OM
  • Carbon Footprint Of The Distribution Phase A4
    • 0.209015027
    • 0.2 kg CO2 eq.
  • Tightening Torque
    • 3.9-3.9 N.m 2.5-6 mm² (AWG 14...AWG 10)
    • 5.6-5.6 N.m 10-70 mm² (AWG 8...AWG 2/0)
  • AWG Gauge
    • AWG 12...AWG 2/0 aluminium
    • AWG 14...AWG 2/0 copper
  • Product Destination
    • NF panelboard
  • UE Rated Operational Voltage
    • 600Y/347 V AC
  • Important Information Attributes
    • B2B Bullet Point 1 : Used in lighting panelboards
    • B2B Bullet Point 2 : Superior overload and short circuit protection
    • B2B Bullet Point 3 : From 15A to 125A ratings
    • B2B Bullet Point 4 : Troubleshoot faster with Visi-Trip™
    • B2B Bullet Point 5 : UL listed, CSA, and HOM certified
    • B2B Bullet Point 6 : Made to last 20 years
    • B2B Bullet Point 7 : Schneider Electric empowers all to make the most of energy and resources, bridging progress and sustainability for all
    • B2B Bullet Point 8 : This product is TAA compliant.
    • Local Data Status : Publishable
    • Local Publishable Date : 2025-07-18
    • Device Type : LV equipment - Low voltage circuit breaker
    • Serviceability : No
    • Traceability : Yes
    • Field Service Division : PPIBS
    • Average Life Duration : 15 year(s)
    • Manufacturing Carbon Footprint : 7.9913286486
    • Distribution Carbon Footprint : 0.209015027
    • Installation Carbon Footprint : 0.0430429622
    • Use Carbon Footprint : 50.548
    • End Of Life Carbon Footprint : 0.2399876757
    • Legacy WEEE Scope : Out
    • Scope Perimeter : Outside of Europe
    • EOLI Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI2212008
    • Reach Full Compliance Status : Reference contains Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : CONTAINS_SVHC
    • Reach Compliance Directive : Reference contains Substances of Very High Concern above the threshold
    • ROHS EUR In Scope : No
    • ROHS EUR Status : Compliant with Exemptions
    • ROHS EUR Conformity Date : 2534
    • ROHS EUR Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
    • ROHS EUR Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
    • China ROHS In Scope : No
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Return Indicator : Y
    • WD Status : 1 - GSC certified
    • Tier Id : 1
    • Tier : 1
    • Function Option Id : STANDARD
    • Function Option : Standard
    • Market Segmentation Id : COMMERCIAL
    • Market Segmentation : Commercial
    • H And D Domain : Safety
    • H And D Subrange : COM
    • H And D Enrichment Assignment : no
    • H And D Enrichment Function : MCB
    • H And D Enrichment Class 3 : Circuit Breakers
    • H And D Enrichment Class 4 : MCB UL 3P
    • Device Short Name : EDB
    • Energy Efficiency Optimized : False
    • Holding Current : 630 A
    • Module Type : E-Frame
    • Number Of Poles : 3
    • Number Of Spaces : 3
    • Number Of Spaces Required : 3
    • Package Weight Lbs : 1.588 kg
    • Product Availability : Stock - Normally stocked in distribution facility
    • Product Or Component Type : circuit-breaker
    • Range Of Product : 125 A Frame EDB-EGB-EJB
    • Returnability : Yes
    • Sustainable Packaging : Yes
    • Total Lifecycle Carbon Footprint : 59 kg CO2 eq.
    • Carbon Footprint Kg Co2 Eq Total Life Cycle : 59.0313743135
    • Relationship Type : Compatible relationship
    • Pep Code : ENVPEP2212008
    • Pep Verification Date : 2021-11-01
    • PCR Version : PCR-ed3-EN-2015 04 02
    • PSR Version : PSR-0005-ed2-EN-2016 03 29
    • Type Of Verification For The Pep : Independent internal review
    • Product Weight In G : 1620
    • Functional Unit Description : Protect during 20 years the installation against overloads and short-circuits in circuit with assigned voltage 277 VAC and rated current 20 A. This protection is ensured in accordance with the following parameters: - Number of poles 1P - Rated brea
    • Functional Unit Quantity : 1
    • Functional Unit Unit : unit
    • Reference Lifetime In Y : 20
    • Energy Consumption On Product Lifetime In Kwh : 73.00584
    • Energy Model Manufacturing A1 A3 : Energy model used: Mexico
    • Energy Model Installation A5 : Electricity mix; AC; 120V; US
    • Energy Model Use B6 : Electricity mix; AC; 120V; US
    • Energy Model End Of Life C1 C4 : Electricity mix; AC; 120V; US
    • Components For Re Use Kg Total Life Cycle : 0
    • Components For Re Use Kg Manufacturing A1 A3 : 0
    • Components For Re Use Kg Distribution A4 : 0
    • Components For Re Use Kg Installation A5 : 0
    • Components For Re Use Kg Operational Energy Use B6 : 0
    • Components For Re Use Kg End Of Life C1 C4 : 0
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb Total Life Cycle : 0.0018905676
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb Manufacturing A1 A3 : 0.0018900584
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb Distribution A4 : 0.0000000084
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb Installation A5 : 0.0000000016
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb Operational Energy Use B6 : 0.0000004968
    • Depletion Of Abiotic Resources Elements Kg Equivalent Sb End Of Life C1 C4 : 0.0000000025
    • Depletion Of Abiotic Resources Fossil Fuels Mj Total Life Cycle : 697.0270091892
    • Depletion Of Abiotic Resources Fossil Fuels Mj Manufacturing A1 A3 : 77.0901081081
    • Depletion Of Abiotic Resources Fossil Fuels Mj Distribution A4 : 2.9364908108
    • Depletion Of Abiotic Resources Fossil Fuels Mj Installation A5 : 0.5581118919
    • Depletion Of Abiotic Resources Fossil Fuels Mj Operational Energy Use B6 : 615.44
    • Depletion Of Abiotic Resources Fossil Fuels Mj End Of Life C1 C4 : 1.0022983784
    • Exported Energy Mj By Energy Vector Total Life Cycle : 0.0025092049
    • Exported Energy Mj By Energy Vector Manufacturing A1 A3 : 0.0002358632
    • Exported Energy Mj By Energy Vector Distribution A4 : 0
    • Exported Energy Mj By Energy Vector Installation A5 : 0.0022733416
    • Exported Energy Mj By Energy Vector Operational Energy Use B6 : 0
    • Exported Energy Mj By Energy Vector End Of Life C1 C4 : 0
    • Hazardous Waste Disposed Of Kg Total Life Cycle : 26.5370729202
    • Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 23.8078702703
    • Hazardous Waste Disposed Of Kg Distribution A4 : 0
    • Hazardous Waste Disposed Of Kg Installation A5 : 0.0000021094
    • Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 1.3515
    • Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 1.3777005405
    • Materials For Energy Recovery Kg Total Life Cycle : 0.0529135784
    • Materials For Energy Recovery Kg Manufacturing A1 A3 : 0
    • Materials For Energy Recovery Kg Distribution A4 : 0
    • Materials For Energy Recovery Kg Installation A5 : 0
    • Materials For Energy Recovery Kg Operational Energy Use B6 : 0
    • Materials For Energy Recovery Kg End Of Life C1 C4 : 0.0529135784
    • Materials For Recycling Kg Total Life Cycle : 1.1799642162
    • Materials For Recycling Kg Manufacturing A1 A3 : 0.1513517838
    • Materials For Recycling Kg Distribution A4 : 0
    • Materials For Recycling Kg Installation A5 : 0.7897018378
    • Materials For Recycling Kg Operational Energy Use B6 : 0
    • Materials For Recycling Kg End Of Life C1 C4 : 0.2389105946
    • Net Use Of Fresh Water M3 Total Life Cycle : 0.2245273192
    • Net Use Of Fresh Water M3 Manufacturing A1 A3 : 0.1350116757
    • Net Use Of Fresh Water M3 Distribution A4 : 0.0000187062
    • Net Use Of Fresh Water M3 Installation A5 : 0.0000047028
    • Net Use Of Fresh Water M3 Operational Energy Use B6 : 0.089339
    • Net Use Of Fresh Water M3 End Of Life C1 C4 : 0.0001532345
    • Non Hazardous Waste Disposed Of Kg Total Life Cycle : 9.9682060346
    • Non Hazardous Waste Disposed Of Kg Manufacturing A1 A3 : 2.2223772973
    • Non Hazardous Waste Disposed Of Kg Distribution A4 : 0.0074263427
    • Non Hazardous Waste Disposed Of Kg Installation A5 : 0.0058337514
    • Non Hazardous Waste Disposed Of Kg Operational Energy Use B6 : 7.7289
    • Non Hazardous Waste Disposed Of Kg End Of Life C1 C4 : 0.0036686432
    • Ozone Depletion Kg Equivalent Cfc 11 Total Life Cycle : 0.0000022662
    • Ozone Depletion Kg Equivalent Cfc 11 Manufacturing A1 A3 : 0.0000013403
    • Ozone Depletion Kg Equivalent Cfc 11 Distribution A4 : 0.0000000004
    • Ozone Depletion Kg Equivalent Cfc 11 Installation A5 : 0.0000000001
    • Ozone Depletion Kg Equivalent Cfc 11 Operational Energy Use B6 : 0.0000009168
    • Ozone Depletion Kg Equivalent Cfc 11 End Of Life C1 C4 : 0.0000000086
    • Radioactive Waste Disposed Of Kg Total Life Cycle : 0.0023918775
    • Radioactive Waste Disposed Of Kg Manufacturing A1 A3 : 0.0015835719
    • Radioactive Waste Disposed Of Kg Distribution A4 : 0.0000052893
    • Radioactive Waste Disposed Of Kg Installation A5 : 0.0000011489
    • Radioactive Waste Disposed Of Kg Operational Energy Use B6 : 0.00079524
    • Radioactive Waste Disposed Of Kg End Of Life C1 C4 : 0.0000066275
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 769.5610664865
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 125.1690810811
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 2.9513772973
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.5613518919
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 639.64
    • Total Use Of Non Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 1.2392562162
    • Total Use Of Primary Energy During The Life Cycle Mj Total Life Cycle : 842.3905928649
    • Total Use Of Primary Energy During The Life Cycle Mj Manufacturing A1 A3 : 157.1224864865
    • Total Use Of Primary Energy During The Life Cycle Mj Distribution A4 : 2.9553178378
    • Total Use Of Primary Energy During The Life Cycle Mj Installation A5 : 0.5622188108
    • Total Use Of Primary Energy During The Life Cycle Mj Operational Energy Use B6 : 680.51
    • Total Use Of Primary Energy During The Life Cycle Mj End Of Life C1 C4 : 1.2405697297
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 72.8329062804
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 31.9577837838
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.0039385265
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.0008729085
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 40.869
    • Total Use Of Renewable Primary Energy Resources Primary Energy And Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0.0013110616
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 9.5308540541
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 9.5308540541
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
    • Use Of Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 760.0337151351
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 115.6417297297
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 2.9513772973
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.5613518919
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 639.64
    • Use Of Non Renewable Primary Energy Excluding Non Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 1.2392562162
    • Use Of Non Renewable Secondary Fuels Mj Total Life Cycle : 0
    • Use Of Non Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
    • Use Of Non Renewable Secondary Fuels Mj Distribution A4 : 0
    • Use Of Non Renewable Secondary Fuels Mj Installation A5 : 0
    • Use Of Non Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
    • Use Of Non Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 3.4531394595
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 3.4531394595
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 0
    • Use Of Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Total Life Cycle : 69.3801170912
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Manufacturing A1 A3 : 28.5049945946
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Distribution A4 : 0.0039385265
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Installation A5 : 0.0008729085
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj Operational Energy Use B6 : 40.869
    • Use Of Renewable Primary Energy Excluding Renewable Primary Energy Resources Used As Raw Materials Mj End Of Life C1 C4 : 0.0013110616
    • Use Of Renewable Secondary Fuels Mj Total Life Cycle : 0
    • Use Of Renewable Secondary Fuels Mj Manufacturing A1 A3 : 0
    • Use Of Renewable Secondary Fuels Mj Distribution A4 : 0
    • Use Of Renewable Secondary Fuels Mj Installation A5 : 0
    • Use Of Renewable Secondary Fuels Mj Operational Energy Use B6 : 0
    • Use Of Renewable Secondary Fuels Mj End Of Life C1 C4 : 0
    • Use Of Secondary Materials Kg Total Life Cycle : 0.715103027
    • Use Of Secondary Materials Kg Manufacturing A1 A3 : 0.715103027
    • Use Of Secondary Materials Kg Distribution A4 : 0
    • Use Of Secondary Materials Kg Installation A5 : 0
    • Use Of Secondary Materials Kg Operational Energy Use B6 : 0
    • Use Of Secondary Materials Kg End Of Life C1 C4 : 0
    • Air Pollution M3 Total Life Cycle : 5763.1025448649
    • Air Pollution M3 Manufacturing A1 A3 : 1450.7318918919
    • Air Pollution M3 Distribution A4 : 8.8916108108
    • Air Pollution M3 Installation A5 : 1.7166745946
    • Air Pollution M3 Operational Energy Use B6 : 4292.7
    • Air Pollution M3 End Of Life C1 C4 : 9.0623675676
    • Water Pollution M3 Total Life Cycle : 3327.31736
    • Water Pollution M3 Manufacturing A1 A3 : 780.7611891892
    • Water Pollution M3 Distribution A4 : 34.3720216216
    • Water Pollution M3 Installation A5 : 6.5288627027
    • Water Pollution M3 Operational Energy Use B6 : 2492
    • Water Pollution M3 End Of Life C1 C4 : 13.6552864865
    • Acidification Of Soil And Water Kg Equivalent So2 Total Life Cycle : 0.0674797874
    • Photochemical Ozone Formation Kg Equivalent C2h4 Total Life Cycle : 0.0098683771
    • Water Eutrophication Kg Equivalent P04 3 Total Life Cycle : 0.0168689033
    • Acidification Of Soil And Water Kg Equivalent So2 Manufacturing A1 A3 : 0.0176798919
    • Acidification Of Soil And Water Kg Equivalent So2 Distribution A4 : 0.0009543114
    • Acidification Of Soil And Water Kg Equivalent So2 Installation A5 : 0.0001793734
    • Acidification Of Soil And Water Kg Equivalent So2 Operational Energy Use B6 : 0.048398
    • Acidification Of Soil And Water Kg Equivalent So2 End Of Life C1 C4 : 0.0002682107
    • Global Warming Kg Equivalent Co2 Total Life Cycle : 59.0313743135
    • Global Warming Kg Equivalent Co2 Manufacturing A1 A3 : 7.9913286486
    • Global Warming Kg Equivalent Co2 Distribution A4 : 0.209015027
    • Global Warming Kg Equivalent Co2 Installation A5 : 0.0430429622
    • Global Warming Kg Equivalent Co2 Operational Energy Use B6 : 50.548
    • Global Warming Kg Equivalent Co2 End Of Life C1 C4 : 0.2399876757
    • Photochemical Ozone Formation Kg Equivalent C2h4 Manufacturing A1 A3 : 0.0020087124
    • Photochemical Ozone Formation Kg Equivalent C2h4 Distribution A4 : 0.0000681022
    • Photochemical Ozone Formation Kg Equivalent C2h4 Installation A5 : 0.0000134048
    • Photochemical Ozone Formation Kg Equivalent C2h4 Operational Energy Use B6 : 0.0077522
    • Photochemical Ozone Formation Kg Equivalent C2h4 End Of Life C1 C4 : 0.0000259577
    • Water Eutrophication Kg Equivalent P04 3 Manufacturing A1 A3 : 0.0037548097
    • Water Eutrophication Kg Equivalent P04 3 Distribution A4 : 0.0002198121
    • Water Eutrophication Kg Equivalent P04 3 Installation A5 : 0.0000435876
    • Water Eutrophication Kg Equivalent P04 3 Operational Energy Use B6 : 0.012755
    • Water Eutrophication Kg Equivalent P04 3 End Of Life C1 C4 : 0.0000956938
  • General Attributes
    • Product Or Component Type : circuit-breaker
    • Range Of Product : 125 A Frame EDB-EGB-EJB
  • Environment Attributes
    • ROHS Exemption Information : Yes
    • China ROHS url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=397149&lang=en-us
    • Take Back : No
    • China ROHS Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Mercury Free : Yes
    • Carbon Footprint : 59.0313743135
    • Circularity Profile : ENVEOLI2212008
    • Environmental Disclosure : ENVPEP2212008
    • EU ROHS Directive : Pro-active compliance (Product out of EU RoHS legal scope)
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP2212008
    • Pep Verification Date : 2021-11-01
    • PCR Version : PCR-ed3-EN-2015 04 02
    • PSR Version : PSR-0005-ed2-EN-2016 03 29
    • Type Of Verification For The Pep : Independent internal review
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
  • Specifications
    • Compliance : TAA
