CONTROL STATION + OPERATORS

SELECTOR SW CONTROL STATION

SQD9001KYSK111 9001KYSK111 785901040071
426.72 / EACH
http://schema.org/OutOfStock
Mayer-DDS-CONTROL STATION + OPERATORS-1
  • Connection Type: Screw Clamp Connector
  • Enclosure Material: Stainless Steel
  • Warranty Length: 18 mth
30 mm heavy duty chromium plated metal push buttons, selector switches, pilot lights, and specialty operators
QTY
  • Features
  • Specifications
  • Prop 65
    • WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Physical Attributes
    • Color Of Cover : grey
    • Housing Color : grey
  • Conformance Attributes
    • Product Certifications : UL Listed
  • Complementary Attributes
    • Ie Rated Operational Current Ac : 10 A
    • Ue Rated Operational Voltage : 300 V
  • Important Information Attributes
    • Environmental Characteristic : resistant against immersion in water, dust and oil resistant
    • Level Or Class : Class II Division 2 Group G, class III
    • Connections Terminals : direct connection AWG 2) solid stranded, direct connection AWG 12) solid stranded, direct connection AWG 24) solid stranded
    • Medium Desc : CONTROL STATION + OPERATORS
    • Local Data Status : Publishable
    • Local Publishable Date : 2026-01-12
    • Global Commercial Status : Commercialised
    • Return Indicator : N
    • Stocking Flag : Y
    • Legacy Weee Scope : In
    • Scope Perimeter : Outside of Europe
    • Eoli Availability Display : Yes
    • End Of Life Doc Ref : ENVEOLI2503027EN
    • Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
    • Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
    • Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
    • Rohs Eur In Scope : No
    • Rohs Eur Status : Compliant
    • Rohs Eur Full Compliance Status : Compliant
    • China Rohs In Scope : Yes
    • With Recycled Cardboard : Yes
    • Without Single Use Plastic : Yes
    • Product Contributes To Saved And Avoided Emissions : No
    • Product Kit Identifier : N
    • Connector Type : screw clamp connector
    • Contact Block Name : KA1
    • Control Station Composition : 1 selector switch 1 NO/1 NC
    • Dc Control Voltage : 125-600 V
    • Device Short Name : 9001KY
    • Enclosure Cubicle Description : wall-mounted enclosure 1 cut-out Ø 30 mm
    • Enclosure Material : Stainless Steel
    • Housing Material : metal
    • Mechanical Interlocking : without mechanical interlock
    • Product Availability : Non-Stock - Not normally stocked in distribution facility
    • Product Or Component Type : control station
    • Product Specific Application : for hoisting and mechanical handling applications
    • Provided Equipment : label plate HAND-OFF-AUTO
    • Range Of Product : Harmony 9001KY
    • Returnability : No
    • Sustainable Packaging : Yes
    • Ac Control Voltage 50 Hz : 125-600 V
    • Ac Control Voltage 60 Hz : 125-600 V
    • Color Of Cover : grey
    • Housing Color : grey
    • Ie Rated Operational Current Ac : 10 A
    • Emergency Power Off Epo : no
    • Pep Code : ENVPEP2503027EN
  • Environment Attributes Main
    • Take Back : Nej
    • Reach Free Shvc : Yes
    • Recycled Metal Content At Cr Level : 0 %
    • China Rohs Regulation : X
    • Toxic Heavy Metal Free : Yes
    • Mercury Free : Yes
    • Ambient Air Temperature For Operation : -25-60 °C
    • Ambient Air Temperature For Storage : -40-70 °C
    • Circularity Profile : ENVEOLI2503027EN
    • Environmental Disclosure : ENVPEP2503027EN
    • Eu Rohs Directive : Compliant
    • Ip Degree Of Protection : IP66
    • Nema Degree Of Protection : NEMA 4X/13
    • Packaging Made With Recycled Cardboard : Yes
    • Packaging Without Single Use Plastic : Yes
    • Reach Free Of Svhc : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Pep Code : ENVPEP2503027EN
  • General Attributes
    • Product Or Component Type : control station
    • Provided Equipment : label plate HAND-OFF-AUTO
    • Range Of Product : Harmony 9001KY
  • ETIM
    • ETIM 8 : EC000225
    • ETIM 9 : EC000225
  • Contractual Warranty Attributes
    • Warranty Period : 18 months
    • Warranty : 18 months
