Circuit breaker, PowerPacT L, 400A, 4 pole, 600VAC, 18kA, lugs, Micrologic 5.3A, 80%

MOLDED CASE CIRCUIT BREAKER 60

SQDLGL46400U43X LGL46400U43X 785901234760
10063.58 / EA
http://schema.org/OutOfStock
Mayer-Circuit breaker, PowerPacT L, 400A, 4 pole, 600VAC, 18kA, lugs, Micrologic 5.3A, 80%-1
  • Certifications: CSA, NOM, UL
  • Depth: 110 mm
  • Height: 340 mm
  • Line Rated Current: 400-400 A
  • Mounting Type: Unit Mount Lug)
  • Net Weight: 6.2 kg
  • Standard: CSA, IEC 60947-2, NEMA, NOM-003-SCFI-2000, UL
  • Storage Temperature: -50-85 °C
  • Strip Length: 31 mm
  • Warranty Length: 18 mth
  • Width: 140 mm
QTY
  • Specifications
  • Specifications
    • Product Or Component Type : circuit breaker
    • Product Name : PowerPact L
    • Device Application : distribution
    • Device Short Name : L-Frame
    • Range : PowerPact
  • Contractual warranty
    • Warranty : 18 months
  • Complementary
    • Mounting Mode : unit mount lug)
    • Network Frequency : 50/60 Hz
    • Wire Stripping Length : 31 mm
    • Terminal Identifier : AL600LS52K4
    • Line Rated Current : 400-400 A
    • Utilisation Category : category A
    • [Ics] Rated Service Breaking Capacity : 65 kA 220/240 V AC 50/60 Hz IEC 60947-2 || 35 kA 380/440/415 V AC 50/60 Hz IEC 60947-2 || 18 kA 500/525 V AC 50/60 Hz IEC 60947-2 || 20 kA 250 V DC IEC 60947-2 || 20 kA 500 V DC IEC 60947-2
    • Long Time Pick-Up Adjustment Range : 0.25...1 x In
    • Trip Unit Technology : electronic, ammeter, Micrologic 5.3 A, LSI
    • Trip Unit Name : Micrologic 5.3 A
    • Height : 340 mm
    • Continuous Current Rating : 80 %
    • Breaking Capacity : 65 kA 240 V AC 50/60 Hz UL 489 || 35 kA 480 V AC 50/60 Hz UL 489 || 18 kA 600 V AC 50/60 Hz UL 489 || 20 kA 250 V DC UL 489 || 20 kA 500 V DC UL 489
    • [Ui] Rated Insulation Voltage : 750 V IEC 60947-2
    • Suitability For Isolation : yes IEC 60947-2
    • [Ue] Rated Operational Voltage : 600 V AC 50/60 Hz IEC 60947-3
    • Communication Interface : Modbus || Ethernet
    • Tightening Torque : 50-50 N.m 70-240 mm² (AWG 2/0...500 kcmil)
    • Mounting Support : lug
    • Breaking Capacity Code : G
    • Poles Description : 4P
    • Local Signalling : ready 1 LED green) || alarm 1 LED 90 % Ir orange) || alarm LED 105 % Ir red) || switched off (OFF) 1 trip indicator green)
    • Number Of Slots : 2 auxiliary switch OF plug-in) || 1 alarm switch SD plug-in) || 1 overcurrent trip switch SDE plug-in) || 1 voltage release MN or MX plug-in)
    • Awg Gauge : AWG 2/0...500 kcmil aluminium/copper
    • Color : Black
    • Width : 140 mm
    • Protection Technology : current limiter
    • Electrical Connection : lugs line || lugs load
    • Depth : 110 mm
    • Net Weight : 6.2 kg
    • [Uimp] Rated Impulse Withstand Voltage : 8 kV IEC 60947-2
    • Control Type : toggle
  • Offer Sustainability
    • China Rohs Regulation : Product out of China RoHS scope. Substance declaration for your information.
    • Circularity Profile : ENVEOLI1406010EN
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1406010EN
    • Sustainable Offer Status : Green Premium product
    • Pvc Free : Yes
    • Eu Rohs Directive : Compliant
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: DINP, which is known to the State of California to cause cancer, and DIDP, which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
  • Environment
    • Ambient Air Temperature For Operation : -2-70 °C
    • Pollution Degree : 3 IEC 60947-1
    • Ambient Air Temperature For Storage : -50-85 °C
    • Standards : UL || CSA || NEMA || NOM-003-SCFI-2000 || IEC 60947-2
    • Product Certifications : UL || CSA || NOM
    • Operating Altitude : < 6561.68 ft (2000 m) without derating || 5000 m with derating
    • Ip Degree Of Protection : front cover IP40
