Cam switch, Harmony K, multifixing, plastic, 3 poles, 2 positions, 90 degree, 20A, 45x45mm,metallic legend, marked 0/1, 35mm black handle

Name: Cam switch, Harmony K, multifixing, plastic, 3 poles, 2 positions, 90 degree, 20A, 45x45mm,metallic legend, marked 0/1, 35mm black handle
Brand: SQUARE D
SKU: SQDK2C003HLH
Price: 167.42 USD
Availability: OutOfStock

SQDK2C003HLH K2C003HLH 3389110979640

167.42 / EA

http://schema.org/OutOfStock

Mayer-DDS-Cam switch, Harmony K, multifixing, plastic, 3 poles, 2 positions, 90 degree, 20A, 45x45mm,metallic legend, marked 0/1, 35mm black handle-1

Country of Origin: Czechia
Warranty Length: 18 mth

QTY

Features
Specifications

Type Of Operator

Black handle 35 mm

Overvoltage Category

class II conforming to IEC 536
class II conforming to NF C 20-030

Uimp Rated Impulse Withstand Voltage

4 kV in isolating function
6 kV IEC 60947-1

Cam Switch Head Type

with front plate 45 x 45 mm

Maximum Operating Rate

2.5 cyc/mn AC-21
2.5 cyc/mn AC-23
2.5 cyc/mn AC-3
8.333 cyc/mn AC-15

Prop 65

WARNING: This product can expose you to chemicals including: Nickel compounds, which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproduc

Standards

IEC 60947-3 power circuit
IEC 60947-5-1 control circuit
CENELEC EN 50013
GB/T 14048.5 control circuit
GB/T 14048.3 power circuit

Ui Rated Insulation Voltage

690 V 3)IEC 60947-1

Presentation Of Legend

with metallic, 0 - 1 black

Ip Degree Of Protection

IP40 conforming to IEC 60529

Electrical Connection

captive screw clamp terminals flexible 2 x 1.5 mm²
captive screw clamp terminals solid 1 x 2.5 mm²
capti

Electrical Durability

200000 cycles AC-23
200000 cycles AC-3
600000 cycles AC-15
600000 cycles AC-21

Vibration Resistance

5 gn 10-150 Hz)IEC 68-2-6

Market Segmentation

Commercial
Industrial

Persona Type Names

Charge Point Operator
End User
Contractor
Original Equipment Manufacturer
OEM - Control Panelbuilder
Panel Builder
Electrician
System Integrator
IT Channel Partner

Persona Type Ids

Short Circuit Protection

20 A cartridge fuse gG

Market Segmentation Id

COMMERCIAL
INDUSTRIAL

Shock Resistance

30 gn IEC 68-2-27

Product Certifications

CSA 240 V 3 hp 3 phase 2
UL 240 V 0.33 hp 1 phase 2
UL 240 V 0.33 hp 1 ph

Physical Attributes

Cad Overall Depth : 87 mm
Cad Overall Height : 45 mm
Cad Overall Width : 45 mm

Important Information Attributes

Country Id : US
Local Data Status : Publishable
Local Publishable Date : 2025-04-05
ETIM 10 : EC001105
Legacy WEEE Scope : In
WEEE Product Category : 5
Scope Perimeter : At least in Europe
EOLI Availability Display : No need of specific recycling operations
Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
ROHS Eur In Scope : No
ROHS Eur Status : Compliant
ROHS Eur Conformity Date : 1930
ROHS Eur Full Compliance Status : Pro-active compliance (Product out of EU RoHS legal scope)
ROHS Eur Full Compliance Status Id : PRO_ACTIVE_COMPLIANCE
China ROHS In Scope : Yes
China ROHS Label : 1
With Recycled Cardboard : No
Without Single Use Plastic : No
Product Contributes To Saved And Avoided Emissions : No
Return Indicator : Y
WD Status : 1 - GSC certified
Tier Id : 2
Tier : 2
Function Option Id : STANDARD
Function Option : Standard
Cam Switch Function : switch
Compatibility Code : K2C
Component Name : K2
Contact Operation : slow-break
Fixing Mode : multifixing
Mechanical Durability : 1000000 cycles
Mounting Location : front
Off Position : with Off position
Package Weight Lbs : 158.000 g
Poles Description : 3P
Positive Opening : with
Product Availability : Non-Stock - Not normally stocked in distribution facility
Product Or Component Type : complete cam switch
Protective Treatment : TC
Range Of Product : Harmony K
Return : without
Returnability : Yes
Rotary Handle Padlocking : without
Short Circuit Current : 10000 A
Sustainable Packaging : No
Switching Angle : 90 °
Switching Positions : right: 0° - 90°
Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
Ith Conventional Free Air Thermal Current : 20 A
Ithe Conventional Enclosed Thermal Current : 16 A

General Attributes

Product Or Component Type : complete cam switch
Range Of Product : Harmony K

Environment Attributes

ROHS Exemption Information : Yes
China ROHS Url : https://checkaproduct.se.com/DistantRequestDispatcher.aspx?action=exportPdfRoHSChina&pid=676992&lang=en-us
Take Back : No
Reach Free Shvc : Yes
Recycled Metal Content At Cr Level : 0 %
China ROHS Regulation : X
Toxic Heavy Metal Free : Yes
Mercury Free : Yes
Ambient Air Temperature For Operation : -25-55 °C
Ambient Air Temperature For Storage : -40-70 °C
Environmental Disclosure : ENVPEP2312055EN
Eu Rohs Directive : Pro-active compliance (Product out of EU RoHS legal scope)
Packaging Made With Recycled Cardboard : No
Packaging Without Single Use Plastic : No
Reach Free Of Svhc : Yes
Reach Regulation : Free of Substances of Very High Concern above the threshold

Contractual Warranty Attributes

Warranty Period : 18 months
Warranty : 18 months
