NEMA Contactor, TeSys N, nonreversing, Size 5, 270A, 200HP at 460VAC, 3 pole, 3 phase, 120VAC 50/60Hz coil, open

NEMA Contactor, TeSys N, nonreversing, Size 5, 270A, 200HP at 460VAC, 3 pole, 3 phase, 120VAC 50/60Hz coil, open

SQDT02GN13G7 T02GN13G7 785901162193
4712.88 / EA
  • Certifications: CSA, UL Listed
  • Contact Configuration: 1 NO
  • Depth: 8.71 in
  • Height: 8.11 in
  • Line Rated Current: 270 A
  • NEMA: 5
  • Net Weight: 20.52 lb
  • Number of Phases: 3
  • Width: 8.39 in
TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. The 3 pole NEMA size 5 contactor has a 270 continuous current rating. It also has ratings of 75 HP at 200, 100 HP at 230 Vac and 200 HP at 460 and 575 VAC. To maximize convenience and to reduce inventory the TeSys N contactor uses the common TeSys accessories. The contactor has a 120 VAC replaceable coil. Contactor is UL listed and CSA Certified. This contactor is 8.11 inches tall, 8.39 inches wide and 8.71 inches deep. It weighs 20.52 lbs. The screw clamp terminals will accept control wires from 16 AWG to 12 AWG. This TeSys N contactor is UL listed and CSA Certified.
  • Product Description
  • Specifications
TeSys N contactors and starters conform to NEMA ICS2 standards. The NEMA size is printed directly on the face of the contactor. The 3 pole NEMA size 5 contactor has a 270 continuous current rating. It also has ratings of 75 HP at 200, 100 HP at 230 Vac and 200 HP at 460 and 575 VAC. To maximize convenience and to reduce inventory the TeSys N contactor uses the common TeSys accessories. The contactor has a 120 VAC replaceable coil. Contactor is UL listed and CSA Certified. This contactor is 8.11 inches tall, 8.39 inches wide and 8.71 inches deep. It weighs 20.52 lbs. The screw clamp terminals will accept control wires from 16 AWG to 12 AWG. This TeSys N contactor is UL listed and CSA Certified.
  • Net Weight : 20.52 lb(US)
  • Maximum Width : 8.39 in
  • Product Certifications : UL Listed || CSA
  • [Uc] Control Circuit Voltage : 120 V AC
  • Electrical Connection : lugs ordered separately
  • Maximum Horse Power Rating : 75 hp 200 V AC || 100 hp 230 V AC || 200 hp 460 V AC || 200 hp 575 V AC
  • Poles Description : 3P
  • Nema Size : 5
  • Product Or Component Type : contactor
  • [Ue] Rated Operational Voltage : 600 V AC
  • Phase : 3 phase
  • Maximum Depth : 8.71 in
  • Range Of Product : TeSys N
  • Auxiliary Contact Composition : 1 NO
  • Control Circuit : common control circuit
  • Contactor Application : non-reversing
  • Nema Degree Of Protection : not rated (open device)
  • Line Rated Current : 270 A
  • Maximum Height : 8.11 in
