TeSys K contactor, 4 poles (4NO), for non-inductive load control applications up to 20A/690V AC-1. It provides a 24V 50/60Hz AC coil, without built-in auxiliary contact, connection by screw clamp terminals. For operating rates until 600 cycles/hour and e

• Uc Control Circuit Voltage
• 24 V AC 50/60 Hz
• Connections Terminals
• screw clamp terminals 1 1.5-4 mm²solid
• screw clamp terminals 1 0.75-4 mm²flexible without cable end
• screw clamp terminals 1 0.75-4 mm²fle
• Prop 65
• WARNING: This product can expose you to chemicals including: Antimony oxide & Antimony trioxide, which is known to the State of California to cause cancer. For more information go to www.P65Warnings.ca.gov
• Carbon Footprint Of The Installation Phase A5
• 0.010778292366401048
• 0 kg CO2 eq.
• Carbon Footprint Of The End Of Life Phase C1 To C4
• 0.3 kg CO2 eq.
• 0.2979052988386399
• Standards
• EN/IEC 60947-4-1
• GB/T 14048.4
• UL 60947-4-1
• CSA C22.2 No 60947-4-1
• JIS C8201-4-1
• IEC 60335-1:Clause 30.2
• IEC 60335-2-40:Annex JJ
• UL 60335-2-40:Annex JJ
• Ue Rated Operational Voltage
• power circuit <= 690 V AC <= 400 Hz
• signalling circuit <= 690 V AC <= 400 Hz
• signalling circuit <= 690 V
• Operating Time
• 10...20 ms coil de-energisation and NO opening
• 10...20 ms coil energisation and NO closing
• Control Circuit Type
• AC 50/60 Hz
• Carbon Footprint Of The Manufacturing Phase A1 To A3
• 1 kg CO2 eq.
• 0.9753347007368284
• Protective Treatment
• TC IEC 60068
• TC DIN 50016
• Average Impedance
• 3 mOhm - Ith 20 A 50 Hz for power circuit
• Electrical Durability
• 0.3 Mcycles 20 A AC-1 <= 690 V
• Market Segmentation
• Commercial
• Industrial
• Persona Type Names
• End User
• Contractor
• Original Equipment Manufacturer
• OEM - Control Panelbuilder
• Panel Builder
• System Integrator
• Add Ons
• LA1KN22
• LA1KN11
• LA1KN40
• LA1KN31
• LA1KN20
• LA1KN04
• LA1KN02
• LA1KN13
• Flame Retardance
• V1 conforming to UL 94
• requirement 2 conforming to NF F 16-101
• requirement 2 conforming to NF F 16-102
• Carbon Footprint Of The Use Phase B2 B3 B4 B6
• 89 kg CO2 eq.
• 88.5193988188928
• Persona Type Ids
• EU
• LC
• OM
• OM8
• PB
• SI
• Safety Reliability Level
• B10d = 1369863 cycles contactor with nominal load EN/ISO 13849-1
• B10d = 1369863 cycles contactor with nominal load EN/ISO 13
• Carbon Footprint Of The Distribution Phase A4
• 0.0699882448144537
• 0.1 kg CO2 eq.
• Ith Conventional Free Air Thermal Current
• 20 A (at 60 °C) for power circuit
• 10 A (at 50 °C) for signalling circuit
• Irms Rated Making Capacity
• 144 A AC for power circuit conforming to IEC 60947
• Mechanical Robustness
• shocks contactor closed, on X axis10 Gn for 11 ms IEC 60068-2-27
• shocks contactor closed, on X axis10 Gn for 11 ms IEC 60068
• Operating Altitude
• 6561.68 ft (2000 m) without derating
• Control Circuit Voltage Limits
• operational: 0.8...1.15 Uc (at <50 °C)
• drop-out: >= 0.20 Uc (at <50 °C)
• Ie Rated Operational Current
• 20 A (at <60 °C) at <= 690 V AC AC-1 for power circuit
• 20 A (at <60 °C) at <= 690 V AC AC
• Icw Rated Short Time Withstand Current
• 115 A 50 °C - 1 s for power circuit
• 105 A 50 °C - 5 s for power circuit
• 10
• Hold In Power Consumption In Va
• 4.5-4.5 VA (at 20 °C)
• Market Segmentation Id
• COMMERCIAL
• INDUSTRIAL
• Inrush Power In Va
• 30-30 VA (at 20 °C)
• Associated Fuse Rating
• 25 A gG at <= 440 V for power circuit
• 25 A aM for power circuit
• Rated Breaking Capacity
• 110 A at 440 V conforming to IEC 60947
• 80 A at 500 V conforming to IEC 60947
• 70 A at 660...690 V con
• Product Certifications
• CB Scheme
• CCC
• UL
• CSA
• EAC
• CE
• UKCA

• Complementary Attributes
• Maximum Operating Rate : 3600 cyc/h
• Uimp Rated Impulse Withstand Voltage : 8 kV
• Important Information Attributes
• Local Data Status : Publishable
• Local Publishable Date : 2025-02-26
• Etim 10 : EC000066
• Device Type : LV equipment - LV contactor
• Serviceability : No
• Traceability : No
• Field Service Division : PPIBS
• Average Life Duration : 20 year(s)
• Manufacturing Carbon Footprint : 0.975334700736828
• Distribution Carbon Footprint : 6.99882448144537e-02
• Installation Carbon Footprint : 1.0778292366401e-02
• Use Carbon Footprint : 88.5193988188928
• End Of Life Carbon Footprint : 0.29790529883864
• Legacy Weee Scope : In
• Weee Product Category : 5
• Scope Perimeter : At least in Europe
• Eoli Availability Display : Yes
• End Of Life Doc Ref : ENVEOLI1503003
• Reach Full Compliance Status : Free of Substances of Very High Concern above the threshold
• Reach Full Compliance Status Id : NOT_CONTAINING_SVHC
• Reach Compliance Directive : Free of Substances of Very High Concern above the threshold
• Rohs Eur In Scope : Yes
• Rohs Eur Status : Compliant
• Rohs Eur Conformity Date : 2448
• Rohs Eur Full Compliance Status : Compliant
• China Rohs Label : 1
• With Recycled Cardboard : Yes
• Without Single Use Plastic : Yes
• Product Contributes To Saved And Avoided Emissions : No
• Return Indicator : Y
• Wd Status : 1 - GSC certified
• Tier Id : 1
• Tier : 1
• Function Option Id : STANDARD
• Function Option : Standard
• Compatibility Code : LC1K
• Contactor Application : resistive load
• Device Application : control
• Device Short Name : LC1K
• Heat Dissipation : 1.3-1.3 W
• Mechanical Durability : 10 Mcycles
• Overvoltage Category : III
• Package Weight Lbs : 179.0 g
• Pole Contact Composition : 4 NO
• Poles Description : 4P
• Product Availability : Stock - Normally stocked in distribution facility
• Product Or Component Type : contactor
• Range : TeSys
• Range Of Product : TeSys K
• Returnability : Yes
• Signalling Circuit Frequency : <= 400 Hz
• Sustainable Packaging : Yes
• Total Lifecycle Carbon Footprint : 90 kg CO2 eq.
• Utilisation Category : AC-1
• Weee Label : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
• Carbon Footprint Kg Co2 Eq Total Life Cycle : 89.87340535564913
• Relationshiptype : Compatible relationship
• Accessories : LA9D90
• Auxiliaries : LA4KE1B
• General Attributes
• Product Or Component Type : contactor
• Range Of Product : TeSys K
• ETIM
• ETIM 8 : EC000066
• ETIM 9 : EC000066
• Environment Attributes
• Take Back : No
• Reach Free Shvc : Yes
• Recycled Metal Content At Cr Level : 0 %
• China Rohs Regulation : X
• Toxic Heavy Metal Free : Yes
• Mercury Free : Yes
• Carbon Footprint : 89.8734053556491
• Circularity Profile : ENVEOLI1503003
• Environmental Disclosure : ENVPEP1503003
• Eu Rohs Directive : Compliant
• Packaging Made With Recycled Cardboard : Yes
• Packaging Without Single Use Plastic : Yes
• Reach Free Of Svhc : Yes
• Reach Regulation : Free of Substances of Very High Concern above the threshold
• Contractual Warranty Attributes
• Warranty Period : 18 months
• Warranty : 18 months
• Specifications
• Country of Origin : Indonesia
• Height : 2.28 in
• Width : 1.77 in
• Depth : 2.24 in
