Load center accessory, QO, mounting base, 3 phase, 12 spaces, 125A main lugs, OEM, neutral busbar

OEM MTG BASE 240VAC 125A 3P 4W

SQDQON312L125I QON312L125I 785901700555
288.47 / EACH
http://schema.org/OutOfStock
Load center accessory, QO, mounting base, 3 phase, 12 spaces, 125A main lugs, OEM, neutral busbar
  • Certifications: CSA, UL Listed
  • Depth: 77 mm
  • Height: 244 mm
  • Line Rated Current: 125 A
  • Net Weight: 1.130 kg
  • Number of Phases: 3
  • Short Circuit Current: 10 kA
  • Warranty Length: 18 mth
  • Width: 270 mm
QTY
  • Product Description
  • Specifications
QO Load Centers offer premium features like QO breakers, ground arc fault interrupters and surge arresters. QO load centers are designed for residential and industrial use to protect electrical systems, equipment and people. Systems are single or three phase and have indoor and outdoor versions. QO Load Centers enable the use of a full complement of accessories. Indoor enclosures are designed to be rotated 180 degrees to accommodate top or bottom service entrance feed. This QO OEM plug on mounting base is for 125A 240 VAC 3 phase 4 wire systems. This OEM mounting base has a 10 kA breaking capacity. The mounting bases is for 12 spaces. This mounting base will accept only QO plug on circuit breakers. The lugs will accept a wire range of 4 AWG to 2/0 AWG copper or aluminum wire. QO OEM bases is UL component recognized.
  • Contractual warranty
    • Warranty : 18 months
  • Specifications
    • Range Of Product : QO
    • [Ue] Rated Operational Voltage : 120/240 V AC
    • Product Or Component Type : mounting base
    • Number Of Spaces : 12
    • Phase : 3 phase
    • Short-Circuit Current : 10 kA
    • Line Rated Current : 125 A
    • Load Center Type : main lugs
  • Complementary
    • Product Certifications : UL Listed || CSA
    • Height : 244 mm
    • Net Weight : 1.130 kg
    • Awg Gauge : AWG 4...AWG 2/0 aluminium/copper
    • Width : 270 mm
    • Wiring Configuration : 4-wire
    • Depth : 77 mm
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP2101006
    • Sustainable Offer Status : Green Premium product
    • Toxic Heavy Metal Free : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: This product can expose you to chemicals including: Lead and lead compounds, which is known to the State of California to cause cancer and birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
    • Reach Free Of Svhc : Yes
    • China Rohs Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
    • Circularity Profile : N/A
    • Eu Rohs Directive : Compliant
