Power quality meter, PowerLogic ION7400, Standard, integrated display, 512 MB, 256 s/c, THD, RVC

PANEL-MOUNT-UTILITY-METER-INT-

SQDMETSEION7400 METSEION7400 3606480930607
9272.99 / EA
http://schema.org/OutOfStock
Power quality meter, PowerLogic ION7400, Standard, integrated display, 512 MB, 256 s/c, THD, RVC
  • Certifications: CE, CULus, N998
  • Depth: 78.5 mm
  • Height: 112 mm
  • IsSustainable: Yes
  • Line Rated Current: 1 A, 10 A, 5 A
  • Mounting Type: Flush-Mounted
  • Net Weight: 706 g
  • Number of Outputs: 1
  • Standard: IEC 61326-1, IEC 61557-12, IEC 62052-11, IEC 62053-22, IEC 62053-24, IEC 62586, IEEE 1588
  • Storage Temperature: -40-85 °C
  • Width: 98 mm
PowerLogic ION7400 utility feeder power meters combine capabilities not typically available in compact meters. They offers a hight flexibility and usability, along with accurate 3-phase energy and power measurements with data logging. Use Power Monitoring Expert software for data analysis or share operation data with SCADA systems through multiple communication channels and protocols. Certified by third party labs for energy accuracy (IEC 62052-11, IEC 62052-22, IEC 62052-24) and power quality (IEC 62586-2, IEC 61000-4-30 Class S). Cybersecurity features include secure protocols (HTTPS, SFTP), security event logging, Syslog protocol. Ability to enable/disable communication ports, and 16 user configurable accounts. With 512 MB of memory to support 50 data logs, 50+ user-definable alarms, waveform captures, 1/2 cycle RMS logging, custom web pages, min/max logs, energy trends, and Time of Use. The ability to timestamp events to +/-1 ms utilizing time synchronization method that include PTP (IEEE1588), NTP, IRIG-B, GPS ASCII (RS485) and network time set function. 3 digital inputs and one digital output. I/O option modules include 2 relays and 6 digital inputs or 2 analog outputs and 4 analog inputs. Wide control power range of 90-415 VAC / 110-415 VDC. Operating environment of -25 to +70C; Humidity rating of 5% to 95%; Altitude up to 3000 m. Panel mounting (1/4 DIN) with integrated display.
QTY
  • Product Description
  • Specifications
PowerLogic ION7400 utility feeder power meters combine capabilities not typically available in compact meters. They offers a hight flexibility and usability, along with accurate 3-phase energy and power measurements with data logging. Use Power Monitoring Expert software for data analysis or share operation data with SCADA systems through multiple communication channels and protocols. Certified by third party labs for energy accuracy (IEC 62052-11, IEC 62052-22, IEC 62052-24) and power quality (IEC 62586-2, IEC 61000-4-30 Class S). Cybersecurity features include secure protocols (HTTPS, SFTP), security event logging, Syslog protocol. Ability to enable/disable communication ports, and 16 user configurable accounts. With 512 MB of memory to support 50 data logs, 50+ user-definable alarms, waveform captures, 1/2 cycle RMS logging, custom web pages, min/max logs, energy trends, and Time of Use. The ability to timestamp events to +/-1 ms utilizing time synchronization method that include PTP (IEEE1588), NTP, IRIG-B, GPS ASCII (RS485) and network time set function. 3 digital inputs and one digital output. I/O option modules include 2 relays and 6 digital inputs or 2 analog outputs and 4 analog inputs. Wide control power range of 90-415 VAC / 110-415 VDC. Operating environment of -25 to +70C; Humidity rating of 5% to 95%; Altitude up to 3000 m. Panel mounting (1/4 DIN) with integrated display.
  • Environment
    • Ambient Air Temperature For Operation : -25-70 °C
    • Electromagnetic Compatibility : electrostatic discharge conforming to IEC 61000-4-2 || radiated radio-frequency electromagnetic field immunity test conforming to IEC 61000-4-3 || electrical fast transient/burst immunity test conforming to IEC 61000-4-4 || surge immunity test conforming to IEC 61000-4-5 || conducted RF disturbances conforming to IEC 61000-4-6 || magnetic field at power frequency conforming to IEC 61000-4-8 || voltage dips and interruptions immunity test conforming to IEC 61000-4-11 || immunity to impulse waves conforming to IEC 61000-4-12 || conducted and radiated emissions conforming to EN 55022 || conducted and radiated emissions conforming to EN 55011 || conducted and radiated emissions conforming to FCC part 15 || conducted and radiated emissions conforming to ICES-003 || conducted RF disturbances (2...150 Hz) conforming to CLC/TR 50579 || surge withstand conforming to IEEE C37.90.1
    • Ambient Air Temperature For Storage : -40-85 °C
    • Relative Humidity : 5-95 %
    • Ip Degree Of Protection : IP54 front: conforming to IEC 60529 || IP30 body: conforming to IEC 60529
    • Operating Altitude : 9842.52 ft (3000 m)
  • Complementary
    • Communication Network Type : IPv6 (internet protocol)
    • Network Frequency : 50 Hz || 60 Hz
    • Communication Port Support : ETHERNET || screw terminal block RS485 || optical probe fiber optic || mini B USB USB
    • Power Quality Analysis : EN 50160 2010 compliance report || IEEE 519 2014 compliance report || IEC 61000-4-30 class S power quality measurement || up to the 63rd harmonic || harmonic distortion || waveform capture || voltage sag and swell detection || programmablity (logic and math functions) || IEC 62586 power quality monitoring || IEC 61000-4-15 disturbance direction detection || rapid voltage change
    • Height : 112 mm
    • Measurement Voltage : 57-400 V AC 42...69 Hz between phase and neutral || 100-690 V AC 42...69 Hz between phases
    • Sampling Rate : 256 samples/cycle
    • Standards : IEC 62053-22 || IEC 62052-11 || IEC 62053-24 || IEC 61557-12 || IEC 61326-1 || IEEE 1588 || IEC 62586
    • Memory Capacity : 512 MB
    • Number Of Outputs : 1 pulse
    • Product Certifications : CE || cULus || N998
    • Type Of Measurement : current || voltage || frequency || active and reactive power total || apparent power total || power factor total || active and reactive power per phase, rms || apparent power per phase, rms || power factor per phase, rms || active and reactive energy || apparent energy
    • Communication Port Protocol : Modbus RTU 115 kbauds - 2-wire || ION 115 kbauds - 2-wire || DNP3 || IEC 61850 || Modbus TCP/IP || Ethernet Modbus TCP/IP daisy chain 10/100 Mbit/s || RSTP 801.1d 2004 || Ansi C12.19 || DLMS
    • Frequency Measurement Range : 42-69 Hz
    • Communication Service : DHCP || RSTP support || NTP time synchronization || SMTP e-mail notification || PTP time synchronization
    • Power Consumption In Va : 18 VA 415 V AC
    • Display Resolution : 320 x 240 pixels QVGA
    • Number Of Inputs : 3 digital 30 V AC || 3 digital 60 V DC
    • Net Weight : 706 g
    • Type Of Installation : indoor installation
    • Depth : 78.5 mm
    • Measurement Current : 50-10000 mA
    • Information Displayed : voltage || current || frequency || power || energy consumption || harmonic distortion
    • [Us] Rated Supply Voltage : 90...415 V AC 45...65 Hz +/- 10 % || 110...415 V DC +/- 10 %
    • Mounting Mode : flush-mounted
    • Measurement Accuracy : current +/- 0.1 % || voltage +/- 0.1 % || active energy +/- 0.2 %
    • Mounting Support : framework
    • Poles Description : 1P + N || 3P || 3P + N
    • Data Recording : alarm logs || waveform logs || sequence of event recording || event logs || sag and swell logs || data logs || harmonics logs || GPS synchronisation || time stamping || trending/forecasting || min/max of instantaneous values || 50 data recorders
    • Line Rated Current : 10 A || 5 A || 1 A
    • Cybersecurity : Syslog protocol support || robust security logs || enable/disable communication ports || password protection || port hardening
    • Isolation Voltage : III400-690 V conforming to IEC 61010-1:ed. 3 || III400-690 V conforming to EN 61010-1:ed. 3 || III347-600 V conforming to UL 61010-1:ed. 3 || III347-600 V conforming to CSA C22.2 No 61010-1:ed. 3
    • Analogue Input Type : voltage (impedance 5 MOhm) || current (impedance 0.3 mOhm)
    • Web Services : customizable home page || file upload/download via FTP || file upload/download via SFTP || web server || alarm notification by e-mail || viewing of captured waveform (FTP) || viewing of captured waveform (web) || HTTPS server
    • Width : 98 mm
    • Display Type : colour TFT LCD
    • Device Application : revenue billing || WAGES metering || data aggregation || power monitoring
    • Accuracy Class : class 0.2S active energy IEC 62053-22 || class 0.2 active energy ANSI C12.20 || class 0.2 active power IEC 61557-12 || class 0.5S reactive energy IEC 62053-24 || class 0.5 power factor IEC 61557-12 || class 0.2 voltage IEC 61557-12 || class 0.2 current IEC 61557-12 || class 0.2 frequency IEC 61557-12 || class 0.2 active energy IEC 61557-12
    • Installation Category : III
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Environmental Disclosure : ENVPEP1512006EN
    • Sustainable Offer Status : Green Premium product
    • Reach Regulation : Reference contains Substances of Very High Concern above the threshold
    • California Proposition 65 : WARNING: Cancer and Reproductive Harm - www.P65Warnings.ca.gov
    • Weee : The product must be disposed on European Union markets following specific waste collection and never end up in rubbish bins.
    • China Rohs Regulation : X
    • Circularity Profile : ENVEOLI1512006EN
    • Eu Rohs Directive : Compliant with Exemptions
  • Specifications
    • Product Or Component Type : power meter
    • Product Name : PowerLogic ION7400
    • Range : PowerLogic
    • Device Short Name : ION7400
