NFC cartridge fuses, Tesys GS, cylindrical 10 mm x 38 mm, fuse type gG, 500VAC, 2 A, without striker

NFC cartridge fuses, Tesys GS, cylindrical 10 mm x 38 mm, fuse type gG, 500VAC, 2 A, without striker

SQDDF2CN02 DF2CN02 338911050206
0.00 / EA
  • Fuse Type: NFC
  • Line Rated Current: 2 A, 500 V
  • Net Weight: 0.01 kg
  • Warranty Length: 18 mth
This is a NFC fuse cartridge for TeSys GS switch-disconnector fuses devices. It is a gG fuse-link that protects against thermal overloads and magnetic over currents, used in standard applications. Its current rating is 2 A and the maximum rated voltage is 500 VAC. It is a cylindrical fuse (NFC type), the dimensions are 10mm x 38mm. It has no striker to indicate when the fuse is blown. This fuse is sold by set of 10 parts.
  • Product Description
  • Specifications
This is a NFC fuse cartridge for TeSys GS switch-disconnector fuses devices. It is a gG fuse-link that protects against thermal overloads and magnetic over currents, used in standard applications. Its current rating is 2 A and the maximum rated voltage is 500 VAC. It is a cylindrical fuse (NFC type), the dimensions are 10mm x 38mm. It has no striker to indicate when the fuse is blown. This fuse is sold by set of 10 parts.
  • Net Weight : 0.01 kg
  • Range Of Product : TeSys fuse-disconnector
  • Line Rated Current : 2 A 500 V
  • Compatibility Code : DF2
  • Warranty : 18 months
  • Quantity Per Set : set of 10
  • Fuse Size : 10 x 38 mm
  • Product Or Component Type : cartridge fuse
  • Device Short Name : DF2
  • [Ue] Rated Operational Voltage : 500 V AC
  • Fuse Curve : gG
  • Fuse Type : NFC
