Multi9 - shunt trip release - MX - 12/24 V AC - 12/24 V DC

Multi9 - shunt trip release - MX - 12/24 V AC - 12/24 V DC

SQDM9A26478 M9A26478 3606480639036
87.26 / EA
http://schema.org/OutOfStock
Mayer-DDS-Multi9 - shunt trip release - MX - 12/24 V AC - 12/24 V DC-1
  • Certifications: PCT, UL, UR
  • Depth: 68 mm
  • Height: 82.5 mm
  • Mounting Type: Fixed
  • Net Weight: 0.06 kg
  • Standard: C22.2 No. 5, EN/IEC 60947-1, EN/IEC 60947-5-1, GB/T 14048.5, UL 1077, UL 489
  • Storage Temperature: -40-85 °C
  • Strip Length: 9 mm
  • Width: 18 mm
This Multi9 MX electrical auxiliary is a shunt trip release. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9mm pitches is 2. The Uc control circuit voltage is 12VAC to 24VAC, or 12VDC to 24VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.
QTY
  • Product Description
  • Specifications
This Multi9 MX electrical auxiliary is a shunt trip release. It is dedicated to Multi9 GFP, C60BP, C60SP, C60BPR. The width in 9mm pitches is 2. The Uc control circuit voltage is 12VAC to 24VAC, or 12VDC to 24VDC. It can be mounted on a DIN rail for modular installation. The operating temperature is -25°C to 50°C. The storage temperature is -40°C to 85°C. This product complies with EN/IEC 60947-1 standard.
  • Offer Sustainability
    • Rohs Exemption Information : Yes
    • Mercury Free : Yes
    • Environmental Disclosure : ENVPEP1305024
    • Sustainable Offer Status : Green Premium product
    • Toxic Heavy Metal Free : Yes
    • Reach Regulation : Free of Substances of Very High Concern above the threshold
    • Reach Free Of Svhc : Yes
    • China Rohs Regulation : Pro-active China RoHS declaration (out of China RoHS legal scope)
    • Circularity Profile : N/A
    • Eu Rohs Directive : Compliant
  • Specifications
    • [Uc] Control Circuit Voltage : 12...24 V AC 50/60 Hz || 12...24 V DC
    • 9 Mm Pitches : 2
    • Product Or Component Type : shunt trip release
    • Range : Multi9
    • Device Short Name : MX
  • Environment
    • Product Certifications : UR || PCT || UL
    • Ambient Air Temperature For Operation : -25-50 °C
    • Standards : EN/IEC 60947-1 || EN/IEC 60947-5-1 || UL 489 || UL 1077 || C22.2 No. 5 || GB/T 14048.5
    • Tropicalisation : 2 EN/IEC 60947-1
    • Pollution Degree : 3
    • Ambient Air Temperature For Storage : -40-85 °C
    • Relative Humidity : 95-95 % 55-55 °C
  • Complementary
    • Height : 82.5 mm
    • Mounting Support : DIN rail
    • Range Compatibility : Multi 9 Multi9 C60 C60BP || Multi 9 Multi9 C60 C60BPR || Multi 9 Multi9 C60 C60SP || Multi 9 Multi9 GFP GFP || Multi 9 Multi9 C60H-DC C60H-DC
    • Comb Busbar And Distribution Block Compatibility : top YES
    • Net Weight : 0.06 kg
    • Wire Stripping Length : 9 mm for bottom connection
    • Connections - Terminals : clamp terminal bottom) - 1 2.5-2.5 mm² AWG 14) - rigid || clamp terminal bottom) - 2 1.5-1.5 mm² AWG 16) - rigid
    • Mounting Mode : fixed
    • Local Signalling : action indicator
    • Width : 18 mm
    • Depth : 68 mm
    • Tightening Torque : 1-1 N.m bottom
